Sony HXCU-100 Service Manual

4-3 (E)
HXCU-100
V04: SCENE FILE
Menu screen Item Description
<SCENE FILE> → V04 TOP
1 2 3 4 5 STORE
STANDARD
MEMORY STICK
READ (MS → CAM)
WRITE(CAM→ MS )
FILE ID:
CAM CODE
DATE
1 to 5, STORE When STORE operation is not used:
Call the relevant scene fi le using the fi le
number selection menu.
After that, the indication of “STORE” is
highlighted.
To cancel the call, select the fi le number
again.
When STORE operation is used:
Place the cursor at “STORE” and turn the
CANCEL/ENTER lever to the ENTER side.
A message “STORE NO?” appears and the
indication of “STORE” is highlighted.
Save the relevant scene fi le using the fi le
number selection menu.
STANDARD Calls the registered reference fi le.
READ (MS→CAM) Reads the scene fi le from the memory stick
and transfers it to the camera.
WRITE (CAM→MS) Acquires the scene fi le stored in the camera
using the fi le transfer, and writes it to the
memory stick.
FILE ID Comment information of the reference fi le
stored in the memory stick.
It can be edited from the menu.
CAM CODE Model name information of the scene fi le
stored in the memory stick.
DATE Scene fi le save date information stored in the
memory stick.
V05: VIDEO LEVEL
Menu screen Item Setting
<VIDEO LEVEL> → V05 TOP
[R] [G] [B] [M]
WHITE : 0 0 0
BLACK : 0 0 0 0
FLARE : 0 0 0
GAMMA : 0 0 0 0
V MOD : 0 0 0 0
FLARE : ON
V MOD : ON D.SHAD: OFF
TEST : OFF
WHITE R/G/B
?99
BLACK R/G/B/M
?99
FLARE R/G/B
?99
GAMMA R/G/B/M
?99
V MOD R/G/B/M
?99
FLARE ON/OFF
V MOD ON/OFF
D.SHAD ON/OFF
TEST OFF/1/2
