Sony HXCU-TX70 User Manual

M03: PLD UPDATE
Menu screen Item Description
<PLD UPDATE> → M03 TOP
POST : V1.02
SY : V1.00
DM : V1.02
ALL
AUTO

POST POST version information
SY SY version information
DM DM version information
ALL Upgrades all ROM files stored in the Memory
Stick.
AUTO Upgrades only files later than the current version
of relevant ROMs in the Memory Stick.
M04: OTHERS
Menu screen Item Setting
<OTHERS> → M04 TOP
CAM POWER REMOTE: NORMAL
REFERENCE MODE : AUTO
SDI-MONI : MONI
GRAY LINE : ON
RX WARNING : ACTIVE
DT-BAR:MIX OFF V 1 H C
VIDEO PAYLOAD ID:
NEW SMPTE352M(2011)
CAM POWER REMOTE NORMAL/BACKUP
REFERENCE MODE AUTO/MANUAL
SDI-MONI CLEAN/MONI
GRAY LINE ON/OFF
RX WARNING ACTIVE
DT-BAR MIX ON/MIX OFF
VIDEO PAYLOAD ID NEW SMPTE352M(2011)
/OLD SMPTE352M(2010)
M05: ANALOG VIDEO
VBS/PIX/WF connector output cropping level adjustment. The setting values are stored in the EEPROM on the DPR-361
board.
Menu screen Item Setting Description
<ANALOG VIDEO> → M05 TOP
TRIM ADJ
VBS LEVEL : 80 (80)
PIX LEVEL : 80 (80)
WFM LEVEL : 80 (80)
COMPONENT LEVEL
RGB/YCD: 80 (80)
PR/R/R-Y BAL: 80
PB/B/B-Y BAL: 80
WRITE CLEAR
VBS LEVEL TRIM 00h to FFh
PIX LEVEL TRIM
WFM LEVEL TRIM
COMPONENT LEVEL
RGB/YCD TRIM
PR/R/R-Y BAL TRIM
PB/B/B-Y BAL TRIM
VBS LEVEL ADJ 00h to FFh Only display
PIX LEVEL ADJ
WFM LEVEL ADJ
COMPONENT LEVEL
RGB/YCD ADJ
PR/R/R-Y BAL ADJ
PB/B/B-Y BAL ADJ
WRITE Writes the above cropping
setting values to the EE-
PROM.
CLEAR Clears the above adjustment
values.
HXCU-TX70
3-14
