SERVICE MANUAL
Ver. 1.5 2007.03
SUPPLEMENT-1
Subject: MAIN board and JACK board changed to suffix-12
from suffix-11.
9-877-170-81
ICD-U50/U60/U70
US Model
ICD-U50/U60/U70
Canadian Model
ICD-U70
AEP Model
ICD-U60/U70
UK Model
ICD-U60/U70
E Model
Chinese Model
ICD-U50/U60/U70
Tourist Model
ICD-U60
Part number of printed wiring board changed to suffix-12 from suffix-11.
It has any difference between suffix-11 and suffix-12.
This supplement-1 describes the difference in the two boards.
Refer to original service manual (9-877-170-0[]) for other information.
•How to distinguish
Location of parts number on changed printed wiring board
After Change : 1-870-035-12
Befor Change : 1-870-035-11
After Change : 1-870-036-12
Befor Change : 1-870-036-11
MAIN BOARD (SIDE A)
JACK BOARD (SIDE B)
