Sony KV-29LS30E - Page 37

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
47
< CAPACITOR >
C002 1-163-233-91 CERAMIC CHIP 18PF 5.00% 50V
C004 1-163-037-91 CERAMIC CHIP 0.022UF 10.00% 50V
C005 1-126-935-91 ELECT 470UF 20.00% 10V
C006 1-163-233-91 CERAMIC CHIP 18PF 5.00% 50V
C009 1-164-004-91 CERAMIC CHIP 0.1UF 10.00% 25V
C010 1-164-005-91 CERAMIC CHIP 0.47UF 16V
C011 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
C012 1-126-963-91 ELECT 4.7UF 20.00% 50V
C013 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C014 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C015 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C016 1-216-295-91 SHORT 0
C018 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C020 1-164-004-91 CERAMIC CHIP 0.1UF 10.00% 25V
C021 1-163-037-91 CERAMIC CHIP 0.022UF 10.00% 50V
C022 1-126-935-91 ELECT 470UF 20.00% 10V
C025 1-126-935-91 ELECT 470UF 20.00% 16V
C026 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C027 1-164-004-91 CERAMIC CHIP 0.1UF 10.00% 25V
C028 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C030 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C033 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C035 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C036 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C037 1-137-354-91 FILM 0.01UF 5.00% 100V
C038 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C039 1-164-505-91 CERAMIC CHIP 2.2UF 16V
C040 1-163-017-91 CERAMIC CHIP 0.0047UF 10.00% 50V
C042 1-162-625-91 CERAMIC CHIP 0.0047UF 5.00% 50V
C043 1-163-037-91 CERAMIC CHIP 0.022UF 10.00% 50V
C044 1-164-346-91 CERAMIC CHIP 1UF 16V
C045 1-164-489-91 CERAMIC CHIP 0.22UF 10.00% 16V
C046 1-163-037-91 CERAMIC CHIP 0.022UF 10.00% 50V
C047 1-126-935-91 ELECT 470UF 20.00% 16V
C053 1-164-004-91 CERAMIC CHIP 0.1UF 10.00% 25V
C055 1-126-960-91 ELECT 1UF 20.00% 50V
C100 1-126-933-91 ELECT 100UF 20.00% 16V
C103 1-126-965-91 ELECT 22UF 20.00% 50V
C105 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C106 1-126-933-91 ELECT 100UF 20.00% 16V
C112 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C204 1-115-340-91 CERAMIC CHIP 0.22UF 10.00% 25V
C211 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C213 1-163-249-91 CERAMIC CHIP 82PF 5.00% 50V
C214 1-163-139-91 CERAMIC CHIP 820PF 5.00% 50V
C215 1-163-084-91 CERAMIC CHIP 1.5PF 0.25PF 50V
C216 1-163-117-91 CERAMIC CHIP 100PF 5.00% 50V
C217 1-163-084-91 CERAMIC CHIP 1.5PF 0.25PF 50V
F2 A
*A-1625-001-A F2 Board, Complete
4-203-258-02 HOLDER, LED
*4-374-846-01 COVER, CAPACITOR, CAP TYPE
< CAPACITOR >
C2601 1-113-924-51 CERAMIC 0.0047UF 20.00% 250V
C2901 1-126-964-91 ELECT 10UF 20.00% 50V
C2902 1-104-665-91 ELECT 100UF 20.00% 25V
< CONNECTOR >
CN2601 *1-580-844-11 PIN, CONNECTOR (POWER)
CN2602 1-695-915-21 TAB (CONTACT)
CN2603 *1-691-291-11 PIN, CONNECTOR (PC BOARD) 5P
CN2901 *1-564-510-51 PLUG, CONNECTOR 7P
< DIODE >
D2901 8-719-923-60 DIODE MTZJ-T-77-9.1A
D2902 8-719-923-60 DIODE MTZJ-T-77-9.1A
D2903 8-719-302-45 DIODE SEL1210S-D
< FUSE >
F2601 £ 1-576-232-11 FUSE (H.B.C.) 5A/250V
£ *1-533-725-11 HOLDER, FUSE (F2601)
< IC >
IC2901 8-742-180-30 HYB IC SBX3081-51 (30)
< RESISTOR >
R2601 1-202-719-91 SOLID 1M 10% 1/2W
R2901 1-249-401-91 CARBON 47 5% 1/4W
R2902 1-247-807-91 CARBON 100 5% 1/4W
< SWITCH >
S2601 £ 1-571-433-31 SWITCH, PUSH (AC POWER)
< VARISTOR >
VDR2601 1-803-830-31 VARISTOR (ERZV14D621)
*A-1632-925-A A Board, Complete (KV-29LS30E/
KV-29LS30K)
*A-1632-933-A A Board, Complete (KV-29LS30U)
*A-1632-932-A A Board, Complete (KV-29LS35B)
*A-1632-922-A A Board, Complete (KV-29LS35E/
KV-29LS35K)
A Board Common Parts
1-900-903-72 LEAD ASSY, FOCUS
4-382-854-01 SCREW (M3X8), P, SW (+)
4-382-854-01 SCREW (M3X8), P, SW (+)
