Sony KV-29LS30E - Page 41

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
51
< IC >
IC001 8-759-837-20 IC TDA9394H/N1/4/0310
IC004 8-759-575-72 IC M24C08-WMN6T
IC401 8-759-665-11 IC LM393DT
IC501 8-759-192-71 IC STV9379
IC531 8-759-665-11 IC LM393DT
IC601 8-759-670-30 IC MCZ3001D
IC602 8-749-016-19 IC SE135N-LF4
IC604 8-759-668-87 IC BA41W12ST-V5
IC608 8-759-591-02 IC L78L33ABZ-AP
IC609 8-759-468-89 IC TOP209P
IC1201 8-759-831-56 IC TDA7497
< JACK >
J401 1-766-296-21 CONNECTOR, DUAL SCART
J404 1-784-632-11 JACK, PIN 2P
< COIL >
L001 1-408-611-21 INDUCTOR 47UH
L004 1-408-611-21 INDUCTOR 47UH
L006 1-408-611-21 INDUCTOR 47UH
L027 1-216-295-91 SHORT 0
L101 1-412-533-41 INDUCTOR 47UH
L102 1-408-611-21 INDUCTOR 47UH
L103 1-412-002-41 INDUCTOR 4.7UH
L104 1-412-002-41 INDUCTOR 4.7UH
L201 1-408-602-21 INDUCTOR 8.2UH
L202 1-408-591-21 INDUCTOR 1UH
L203 1-408-602-21 INDUCTOR 8.2UH
L205 1-408-591-21 INDUCTOR 1UH
L206 1-535-143-61 LEAD, JUMPER (5.0MM)
L207 1-408-591-21 INDUCTOR 1UH
L401 1-410-993-42 INDUCTOR 1UH
L403 1-410-993-42 INDUCTOR 1UH
L404 1-410-993-42 INDUCTOR 1UH
L405 1-535-143-61 LEAD, JUMPER (5.0MM)
L406 1-535-143-61 LEAD, JUMPER (5.0MM)
L410 1-216-025-91 RES-CHIP 100 5% 1/10W
L430 1-412-002-41 INDUCTOR 4.7UH
L446 1-216-295-91 SHORT 0
L448 1-216-295-91 SHORT 0
L501 1-414-187-31 INDUCTOR 47UH
L502 1-412-529-41 INDUCTOR 22UH
L503 1-412-521-41 INDUCTOR 4.7UH
L504 1-535-143-61 LEAD, JUMPER (5.0MM)
L505 1-412-542-41 INDUCTOR 270UH
L507 1-412-533-41 INDUCTOR 47UH
L532 1-412-553-41 INDUCTOR 3.3MH
L533 1-406-989-11 INDUCTOR 10MH
L534 1-216-025-91 RES-CHIP 100 5% 1/10W
L535 1-459-111-21 INDUCTOR 10MH
L601 1-408-603-21 INDUCTOR 10UH
L602 1-408-611-21 INDUCTOR 47UH
L603 1-535-143-61 LEAD, JUMPER (5.0MM)
L1200 1-535-143-61 LEAD, JUMPER (5.0MM)
L1201 1-535-143-61 LEAD, JUMPER (5.0MM)
L1203 1-535-143-61 LEAD, JUMPER (5.0MM)
< PHOTO COUPLER >
PH601 £ 8-749-016-21 IC TCET1103G
< IC LINK >
PS1201 1-535-143-31 LEAD, JUMPER 15.0MM
< TRANSISTOR >
Q013 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q014 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q049 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q202 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q203 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q212 8-729-422-33 TRANSISTOR 2SD601A-Q-TX
Q401 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q409 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q411 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q532 8-729-050-48 TRANSISTOR IRF614-005
Q533 8-729-049-08 TRANSISTOR BU2515DX-127
Q535 8-729-053-33 TRANSISTOR IRF614-037
Q570 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q601 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q602 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q603 8-729-029-56 TRANSISTOR DTA144ESA
Q604 8-729-030-02 TRANSISTOR DTC144ESA
Q606 8-729-053-36 TRANSISTOR 2SK2640-01MR
Q607 8-729-053-36 TRANSISTOR 2SK2640-01MR
Q608 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q609 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q1210 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1211 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1230 8-729-027-56 TRANSISTOR DTC143TKA-T146
Q1231 8-729-027-56 TRANSISTOR DTC143TKA-T146
Q1232 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q1233 8-729-026-49 TRANSISTOR 2SA1037AK-T146
< RESISTOR >
JR4 1-216-295-91 SHORT 0
JR7 1-216-295-91 SHORT 0
JR10 1-216-295-91 SHORT 0
A
