Sony KV-29LS30E - Page 45

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
55
C
VM
< THERMISTOR >
TH601 1-803-586-41 THERMISTOR
THP601 £ 1-803-951-11 THERMISTOR, PTC
< CRYSTAL >
X001 1-578-774-71 VIBRATOR, CRYSTAL
X201 1-760-628-21 VIBRATOR, CRYSTAL
A Board Variant Parts KV-29LS30/29LS35
< IC >
IC201 6-700-410-01 IC MSP3410G-PP-B8 (KV-29LS30)
6-700-374-01 IC MSP3411G-PP-B9 (KV-29LS35)
< TUNER >
TU101 8-598-533-00 FRONTEND BTF-EC411 (KV-29LS30E/29LS30K/
KV-29LS35E/29LS35K)
8-598-529-00 FRONTEND BTF-EU611 (KV-29LS30U)
8-598-535-10 FRONTEND BTF-EF411 (KV-29LS35B)
*A-1639-019-A C Board, Complete
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C701 1-136-189-91 MYLAR 0.1UF 10.00% 250V
C702 1-126-964-91 ELECT 10UF 20.00% 50V
C703 1-101-004-91 CERAMIC 0.001UF 50V
C704 1-107-649-91 ELECT 2.2UF 20.00% 250V
C708 1-162-114-51 CERAMIC 0.0047UF 2KV
C710 1-107-652-91 ELECT 10UF 20.00% 250V
C1803 1-101-005-91 CERAMIC 0.022UF 50V
C1804 1-126-964-91 ELECT 10UF 20.00% 50V
C1805 1-101-880-91 CERAMIC 47PF 5.00% 50V
< CONNECTOR >
CN702 1-695-915-21 TAB (CONTACT)
CN703 *1-564-510-51 PLUG, CONNECTOR 7P
CN706 1-695-915-21 TAB (CONTACT)
CN707 *1-564-508-51 PLUG, CONNECTOR 5P
CN1801 *1-564-506-51 PLUG, CONNECTOR 3P
< DIODE >
D701 8-719-991-33 DIODE 1SS133T
D702 8-719-901-83 DIODE 1SS83
D703 8-719-989-09 DIODE 1SS83TA
D705 8-719-936-85 DIODE RGP10GPG23
D706 8-719-901-83 DIODE 1SS83
D707 8-719-901-83 DIODE 1SS83
A
D708 8-719-923-46 DIODE MTZJ-T-77-6.8B
D709 8-719-923-46 DIODE MTZJ-T-77-6.8B
D710 8-719-923-46 DIODE MTZJ-T-77-6.8B
D1801 8-719-048-53 DIODE MTZJ-T-77-10
D1802 8-719-048-53 DIODE MTZJ-T-77-10
D1803 8-719-048-53 DIODE MTZJ-T-77-10
< IC >
IC701 8-759-562-43 IC TDA6108JF/N1B
IC1801 8-759-603-37 IC M5216P
< SOCKET >
J701 £ 1-251-732-11 SOCKET, CRT
< COIL >
L704 1-414-183-31 INDUCTOR 10UH
< RESISTOR >
R701 1-247-903-91 CARBON 1M 5% 1/4W
R702 1-249-429-91 CARBON 10K 5% 1/4W
R703 1-247-903-91 CARBON 1M 5% 1/4W
R704 1-535-143-21 LEAD, JUMPER (12.5MM)
R705 1-215-869-21 METAL OXIDE 1K 5% 1W
R706 1-247-819-91 CARBON 330 5% 1/4W
R712 1-215-869-21 METAL OXIDE 1K 5% 1W
R716 1-247-819-91 CARBON 330 5% 1/4W
R718 1-202-814-91 SOLID 33K 10% 1/2W
R726 1-215-869-21 METAL OXIDE 1K 5% 1W
R727 1-247-819-91 CARBON 330 5% 1/4W
R728 1-249-398-91 CARBON 27 5% 1/4W
R741 1-202-549-81 SOLID 100 20% 1/2W
R1801 1-249-441-91 CARBON 100K 5% 1/4W
R1805 1-249-429-91 CARBON 10K 5% 1/4W
R1806 1-247-899-91 CARBON 680K 5% 1/4W
R1807 1-249-429-91 CARBON 10K 5% 1/4W
R1808 1-249-429-91 CARBON 10K 5% 1/4W
R1809 1-249-429-91 CARBON 10K 5% 1/4W
R1810 1-249-429-91 CARBON 10K 5% 1/4W
< VARIABLE RESISTOR >
RV702 1-225-952-11 RES, ADJ, METAL FILM 110M
*A-1645-045-A VM Board, Complete
< CAPACITOR >
C1701 1-104-665-91 ELECT 100UF 20.00% 25V
C1702 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C1703 1-162-955-91 CERAMIC CHIP 150PF 5.00% 50V
C1704 1-104-665-91 ELECT 100UF 20.00% 25V
