Sony KV-29LS30E - Page 47

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
57
R1713 1-216-809-91 RES-CHIP 100 5% 1/16W
R1714 1-260-089-81 CARBON 150 5% 1/2W
R1719 1-216-822-91 RES-CHIP 1.2K 5% 1/16W
R1720 1-247-863-91 RES-CHIP 22K 5% 1/4W
R1721 1-247-863-91 RES-CHIP 22K 5% 1/4W
R1722 1-216-822-91 RES-CHIP 1.2K 5% 1/16W
R1723 1-249-399-91 CARBON 33 5% 1/4W
R1724 1-216-830-91 RES-CHIP 5.6K 5% 1/16W
R1725 1-247-889-91 RES-CHIP 270K 5% 1/4W
R1726 1-247-889-91 RES-CHIP 270K 5% 1/4W
R1727 1-216-830-91 RES-CHIP 5.6K 5% 1/16W
R1728 1-249-399-91 CARBON 33 5% 1/4W
R1729 1-249-407-91 CARBON 150 5% 1/4W
R1732 1-249-407-91 CARBON 150 5% 1/4W
R1733 1-214-809-81 METAL 5.1 1% 1/2W
R1734 1-214-809-81 METAL 5.1 1% 1/2W
R1735 1-215-922-21 METAL OXIDE 6.8K 5% 3W
R1736 1-215-892-51 CARBON 1K 5% 2W
R1737 1-215-867-21 METAL OXIDE 470 5% 1W
R1739 1-249-379-51 CARBON 0.68 5% 1/4W
R1842 1-216-025-91 RES-CHIP 100 5% 1/10W
R1846 1-216-057-91 RES-CHIP 2.2K 5% 1/10W
R1847 1-216-476-21 METAL OXIDE 180 5% 3W
R1848 1-215-911-21 METAL OXIDE 100 5% 3W
R1903 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1904 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1905 1-216-097-91 RES-CHIP 100K 5% 1/10W
R1906 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1907 1-216-097-91 RES-CHIP 100K 5% 1/10W
R1908 1-216-033-91 RES-CHIP 220 5% 1/10W
R1909 1-215-489-91 METAL 680K 1% 1/4W
R1910 1-216-295-91 SHORT 0
R1911 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1912 1-216-121-91 RES-CHIP 1M 5% 1/10W
R1913 1-216-049-91 RES-CHIP 1K 5% 1/10W
R1914 1-216-057-91 RES-CHIP 2.2K 5% 1/10W
R1915 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R1916 1-216-667-91 METAL CHIP 4.7K 0.5% 1/10W
R1917 1-216-693-91 METAL CHIP 56K 0.5% 1/10W
R1918 1-215-922-91 METAL OXIDE 6.8K 5% 3W
R1919 1-216-675-91 METAL CHIP 10K 0.5% 1/10W
R1920 1-216-295-91 SHORT 0
R1921 1-215-922-91 METAL OXIDE 6.8K 5% 3W
R1922 1-215-919-91 METAL OXIDE 2.2K 5% 3W
R1923 1-216-097-91 RES-CHIP 100K 5% 1/10W
R1924 1-216-097-91 RES-CHIP 100K 5% 1/10W
R1925 1-216-097-91 RES-CHIP 100K 5% 1/10W
R1926 1-216-295-91 SHORT 0
R1931 1-216-691-91 METAL CHIP 47K 0.5% 1/10W
R1953 1-216-107-91 RES-CHIP 270K 5% 1/10W
H2
VM
R1954 1-216-109-91 RES-CHIP 330K 5% 1/10W
R1955 1-216-105-91 RES-CHIP 220K 5% 1/10W
R1956 1-218-463-91 RES-CHIP 8.2M 5% 1/10W
R1957 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1958 1-216-025-91 RES-CHIP 100 5% 1/10W
R1959 1-216-063-91 RES-CHIP 3.9K 5% 1/10W
R1960 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1961 1-216-687-91 METAL CHIP 33K 0.5% 1/10W
R1962 1-216-687-91 METAL CHIP 33K 0.5% 1/10W
R1964 1-216-025-91 RES-CHIP 100 5% 1/10W
R1965 1-216-041-91 RES-CHIP 470 5% 1/10W
R1966 1-215-886-91 METAL OXIDE 100 5% 2W
R1967 1-215-922-51 METAL OXIDE 6.8K 5% 3W
R1968 1-215-886-91 METAL OXIDE 100 5% 2W
R1969 1-216-485-21 METAL OXIDE 5.6K 5% 3W
< TRANSFORMER >
T1901 1-433-849-11 TRANSFORMER, DYNAMIC FOCUS
*A-1646-239-A H2 Board, Complete
< CAPACITOR >
C906 1-126-960-91 ELECT 1UF 20.00% 50V
C907 1-126-960-91 ELECT 1UF 20.00% 50V
< CONNECTOR >
CN906 *1-564-524-11 PLUG, CONNECTOR 9P
CN908 1-564-521-11 PLUG, CONNECTOR 6P
< DIODE >
D902 8-719-929-15 DIODE HZS9.1NB2
D903 8-719-929-15 DIODE HZS9.1NB2
D904 8-719-109-97 DIODE RD6.8ES-B2
D905 8-719-109-97 DIODE RD6.8ES-B2
D908 8-719-923-58 DIODE MTZJ-T-77-9.1A
< JACK >
J900 1-750-264-11 JACK
J901 1-779-947-12 TERMINAL BLOCK, S
< COIL >
L900 1-535-143-61 LEAD, JUMPER (5.0MM)
L901 1-535-143-61 LEAD, JUMPER (5.0MM)
L902 1-535-143-61 LEAD, JUMPER (5.0MM)
L903 1-535-143-61 LEAD, JUMPER (5.0MM)
L904 1-410-119-21 INDUCTOR 1MH
< RESISTOR >
R901 1-249-427-91 CARBON 6.8K 5% 1/4W
R902 1-249-429-91 CARBON 10K 5% 1/4W
