Sony LMD-2140MD - Bezel Assembly

LMD-2140MD
1-5
1-3-3. Bezel Assembly
2 Fourteen screws
(+BVTP 3 x10)
1 Connector
CN1001
3 LCD panel section,
Shield case assembly, etc.
4 Bezel section
5 Eight screws
(+BVTP 3 x 10)
6 Two bracket (A)
assemblies
8 Two bracket (B)
assemblies
7 Eight screws
(+BVTP 3 x 10)
0
Bezel assembly
9 Protection plate
Upper
Side
Upper
Side
Upper
Side
Cushion
Cushion
Cushion
