MDK-IF5K
MDR-IF5/TMR-IF5
SECTION 1
GENERAL
Parts fe eyarti icersit(eya|
Transmitter 3
Charging indicator
Infrared emitters
Power indicator:
Infrared sensors
Positioning the Transmitter
The diagram below illustrates the approximate effective range of
the infrared rays emitted from the transmitter. Position the transmit-
ter so that your listening area is within the effective range.
The infrared rays will not
penetrate walis or opaque
glass, therefore the head-
phones must be used in
“in sight” area of the
transmitter.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK A OR DOTTED
LINE WITH MARK A ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
Contact pins
Quick charge button
DC IN 9V (DC external
power input) jack
Audio input cord -
infrared sensor
Power switch
Head band
Contact holes
Volume controls
Ear pads
