Sony MDR-RF450 - Section 1 Disassembly

– 2 –
SECTION 1
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
1-1. RX BOARD, FE BOARD, RECEIVER (R-CH), SUSPENDER REMOVAL
1-2. BATTERY CASE, RECEIVER (L-CH), SUSPENDER REMOVAL
MDR-RF430
2 Screws +P 2x10
9 Screw
(M1.7x4)
!™ Screw
+P 2x6
3 Screws +P 2x5
!¢ Screw (M 1.7x4)
7 Remove
solder
RX shield plate
!§ Remove solder
Hanger cover (R)
Spacer
Hanger (R)
Suspender
Head band
5 RX board
Housing (R) assy
MDD02 (R-CH)
SW1
Ball shaft holder
Ear pa
d
!¡
!¶
1
!∞
!£
4
8
6
!º
FE board
2 Screws +P 2x10
7 Screw +P 2x6
3 Screws +P 2x5
!¡ Remove solder
Hanger cover (L
)
Suspender
Head band
Battery cover
Battery case
Housing (L) assy
Hanger (L)
MDD01 (L-CH)
Ball shaft holder
Ear pad
9 Screw (M 1.7x4)
1
!º
4
6
!™
8
5
