Sony NEX-5T Instruction Manual

GB
11
Preparing the camera
1)
Accessories for the Smart
Accessory Terminal can also be
attached.
You cannot use the [Self-portrait
Self-timer] function when a flash
HVL-F7S (supplied) or accessories
are attached to the Smart Accessory
Terminal 2.
2)
Do not cover this part during movie
recording.
3)
Do not touch this part directly.
A Image sensor position mark
B Wi-Fi sensor (built-in)
C Charge lamp
D Micro USB terminal
E HDMI terminal (54)
F LCD screen/Touch panel
4)
(34)
G (Playback) button (29)
H Control dial (33)
I MOVIE button (28)
J Soft key A (33)
K Control wheel (32)
L Soft key C (33)
M Soft key B (33)
4)
• You can adjust the LCD screen to
an easily viewable angle and shoot
from any position.
• Tilt the LCD screen upward about
180 degrees when you take a self-
portrait. The 3-second delay self-
timer is automatically selected in
the default setting.
• When storing the LCD screen after
Self-portrait shooting, lower the
LCD screen completely until it fits
against the camera body, then slide
the LCD screen upward until both
the bottoms of the LCD screen and
the camera body are aligned.

Sony NEX-5T Specifications

General

Sensor Type	CMOS
Sensor Size	APS-C (23.5 x 15.6 mm)
Effective Pixels	16.1 MP
ISO Range	100-25600
Autofocus Points	25
Lens Mount	Sony E-mount
Image Processor	BIONZ
Screen Size	3.0"
Screen Resolution	921, 600 dots
Video Resolution	1920 x 1080
Video Frame Rate	60p, 60i, 24p
Maximum Shutter Speed	1/4000 sec
Minimum Shutter Speed	30 sec
Continuous Shooting	10 fps
Built-in Flash	No
External Flash	Yes (via hot shoe)
Wireless Connectivity	Wi-Fi, NFC
Battery	NP-FW50
Battery Life	330 shots
Dimensions	110.8 x 58.8 x 38.9 mm
Weight	276 g (with battery and memory card)
