1
English
Automatic release of BNC-type
connector termination
The BNC-type input connector is terminated at 75 ohms
inside when the BNC-type output connector is open. When
a cable is connected to the BNC-type output connector, the
75-ohm termination is automatically released, and the signal
input through the IN connector is output from the
corresponding OUT connector.
EIA standard 19-inch rack mounting
To mount the monitors in an EIA standard 19-inch rack, use
the MB-507 mounting bracket (not supplied) for the PVM-
96E/PVM-95E, or the MB-502A bracket (not supplied) for
the PVM-146E/PVM-145E. For details, see the appropriate
instruction manual.
Features
Table of Contents
Features .............................................................................. 1
Location and function of parts and controls ........................ 2
Power sources .................................................................... 5
Specifications ...................................................................... 6
This instruction manual covers the PVM-96E, PVM-95E,
PVM-146E and PVM-145E. The differences among the
models are clearly described in the text.
PVM-96E
PVM-95E
PVM-146E
PVM-145E
