SLT-A33/A33L/A33Y/A55/A55V/A55L/A55VL/A55VY_L3
7-3
 D3814 6-500-776-01 DIODEMAZW068H0LS0
 D3815 8-719-084-17 DIODEEMZ6.8ET2R
 D3817 8-719-083-66 DIODEUDZSUSTE-1718B
 D3818 8-719-083-66 DIODEUDZSUSTE-1718B
 D3819 8-719-084-17 DIODEEMZ6.8ET2R
 D3820 8-719-084-17 DIODEEMZ6.8ET2R
 D3821 8-719-084-17 DIODEEMZ6.8ET2R
* D3822 6-502-629-01 DIODE1SS420(TL3SONY.F)
   <FUSE>
0F0501 1-576-958-31 FUSE(4A/24V)
0F0503 1-576-407-31 FUSE(1.4A/36V)
0*F0504 1-576-874-31 FUSE(2.5A/32V)
   <FERRITEBEAD>
* FB1232 1-500-919-21 BEAD,FERRITE
* FB2301 1-400-829-21 BEAD,FERRITE(1005)
* FB2302 1-400-829-21 BEAD,FERRITE(1005)
* FB2303 1-400-829-21 BEAD,FERRITE(1005)
* FB2304 1-400-829-21 BEAD,FERRITE(1005)
   <FLUORESCENTINDICATORTUBE>
 FL1301 1-234-939-21 FILTER,EMIREMOVAL(SMD)
 FL1501 1-234-939-21 FILTER,EMIREMOVAL(SMD)
 FL1502 1-234-939-21 FILTER,EMIREMOVAL(SMD)
   <IC>
* IC0001 6-713-982-01 ICBD8303MUV-E2
* IC0002 6-808-779-01 ICMB44C017BBGF-G-N2ERE1
* IC0004 6-711-661-01 ICNJM2878F4-05(TE2)
* IC0006 6-713-979-01 ICS-1200B30-I6T2G
* IC1001 8-753-341-80 ICCXD4115GG-1-T6
 IC1002 (Notsupplied) ICKFG1G16Q2C-AEB8T
(IC1002issuppliedincludinginAM-022completeboard.)
* IC1003 6-714-401-01 ICK4X1G323PE-8GC6T(SLT-A33/A33L/A33Y)
* IC1003 6-714-773-01 ICK4X2G323PB-8GC6T
(SLT-A55/A55V/A55L/A55VL/A55VY)
* IC1004 6-714-401-01 ICK4X1G323PE-8GC6T(SLT-A33/A33L/A33Y)
* IC1004 6-714-773-01 ICK4X2G323PB-8GC6T
(SLT-A55/A55V/A55L/A55VL/A55VY)
 IC1302 6-708-511-01 ICTC7SG08AFS
* IC1501 6-714-458-01 ICCXD9974GG
* IC1801 8-753-335-26 ICCXD4113GG-T6
 IC1802 6-708-511-01 ICTC7SG08AFS
* IC1901 6-716-188-11 ICICK4X56323PN-8GC6T
* IC2001 6-713-468-01 ICADV7521NKBCBZRL-80
 IC2002 6-705-337-01 ICTK11150CSCL-G
* IC2101 6-712-050-01 ICSN65LVDS301ZQER
 IC2102 6-702-302-01 ICTK11133CSCL-G
* IC2201 6-714-502-01 ICBD2224G-TR
* IC2202 6-714-502-01 ICBD2224G-TR
* IC2301 6-714-036-01 ICAK4646EZ
* IC2302 6-708-446-01 ICR1114Q311D-TR-FA
 IC2303 6-707-702-01 ICNJM2746RB1(TE2)
* IC2401 6-711-661-01 ICNJM2878F4-05(TE2)
(SLT-A55/A55V/A55L/A55VL/A55VY)
* IC2401 6-715-364-01 ICNJM2878F4-45(TE2)(SLT-A33/A33L/A33Y)
* IC2402 6-711-661-01 ICNJM2878F4-05(TE2)
(SLT-A55/A55V/A55L/A55VL/A55VY)
* IC2402 6-715-364-01 ICNJM2878F4-45(TE2)(SLT-A33/A33L/A33Y)
* IC3001 6-716-455-01 IC19A44FDAXBG041A(EL
* IC3002 6-709-668-01 ICS-812C45BPI-C4ZTFG
* IC3003 6-708-446-01 ICR1114Q311D-TR-FA
 IC3004 6-705-027-01 ICBD4840FVE-TR
* IC3005 6-714-057-01 ICBD4827FVE-TR
* IC3101 6-714-058-01 ICBU7050GUW-E2
* IC3201 6-716-506-01 ICMB91F233LALGV-G-13-ERE1
* IC3301 6-714-059-01 ICuPD168165K9-9E5-E1-AT
 IC3303 8-759-082-60 ICTC7S66FU
 IC3304 8-759-082-60 ICTC7S66FU
* IC3401 6-713-980-01 ICLV8406T-TLM-E
* IC3402 6-715-286-01 ICAN41400A-PB
* IC3603 6-715-366-01 ICuPD79F0107FC-402-2N1-E2-A
 IC3604 6-708-327-01 ICTC7WH240FK(TE85R)
 IC3605 6-708-511-01 ICTC7SG08AFS
* IC3801 6-711-661-01 ICNJM2878F4-05(TE2)
 IC3803 6-703-953-01 ICTK11134CSCL-G
(SLT-A55/A55V/A55L/A55VL/A55VY)
* IC3804 6-711-739-01 ICTC7WG126FK
(SLT-A55/A55V/A55L/A55VL/A55VY)
   <JACK>
 J2302 1-793-703-21 JACK(DIA.3.5)
   <COIL>
 L0001 1-457-439-11 INDUCTOR 4.7uH
 L0002 1-456-486-21 INDUCTOR 47uH
* L0003 1-457-614-21 INDUCTOR 10uH
* L0004 1-457-522-21 INDUCTOR 4.7uH
 L0005 1-456-135-11 INDUCTOR 4.7uH
 L0006 1-456-136-21 INDUCTOR 10uH(SLT-A33/A33L/A33Y)
 L0007 1-456-135-11 INDUCTOR 4.7uH
 L0008 1-456-135-11 INDUCTOR 4.7uH
 L0009 1-456-135-11 INDUCTOR 4.7uH
* L1301 1-400-411-21 INDUCTOR 4.7uH
* L1501 1-400-411-21 INDUCTOR 4.7uH
* L1502 1-400-411-21 INDUCTOR 4.7uH
* L1503 1-400-411-21 INDUCTOR 4.7uH
* L1504 1-400-411-21 INDUCTOR 4.7uH
* L1506 1-400-411-21 INDUCTOR 4.7uH
* L1507 1-400-411-21 INDUCTOR 4.7uH
 L2001 1-400-588-11 INDUCTOR 10uH
 L2101 1-400-588-11 INDUCTOR 10uH
 L2302 1-400-317-21 INDUCTOR 100uH
 L2303 1-400-675-11 INDUCTOR 10uH
   <LINEFILTER>
 LF1301 1-457-223-11 COMMONMODECHOKECOIL
* LF2001 1-457-685-11 COMMONMODECHOKECOIL
* LF2002 1-457-685-11 COMMONMODECHOKECOIL
   <TRANSISTOR>
 Q0001 6-551-631-01 TRANSISTOR RN1104MFV(TL3S
 Q0002 6-551-184-01 TRANSISTOR MCH6305-TL-E-S
* Q0003 6-552-239-01 TRANSISTOR QS8K2TRANSISTOR
* Q0004 6-552-239-01 TRANSISTOR QS8K2TRANSISTOR
* Q0005 6-552-490-01 TRANSISTOR SCH1433-S-TL-H
* Q0008 6-552-054-01 TRANSISTOR SCH2825-TL-E
 Q0009 6-551-630-01 TRANSISTOR RN1102MFV(TL3S
 Q0010 6-551-184-01 TRANSISTOR MCH6305-TL-E-S
 Q0011 6-551-631-01 TRANSISTOR RN1104MFV(TL3S
 Q0012 6-551-184-01 TRANSISTOR MCH6305-TL-E-S
 Q0013 6-550-789-01 TRANSISTOR SSM3K15FV(TL3S
 Q0014 6-551-631-01 TRANSISTOR RN1104MFV(TL3S
 Q1301 8-729-053-58 TRANSISTOR RN1904FE(TPLR3)
 Q1801 8-729-055-88 TRANSISTOR MCH3406-TL-E
 Q1802 6-551-346-01 TRANSISTOR LSK3541FS8T2L
* Q1803 6-552-029-01 TRANSISTOR MCH3377-S-TL-E
 Q1804 6-550-576-01 TRANSISTOR SSM6E01TU
 Q1805 6-551-202-01 TRANSISTOR LM6K1FS8T2R
 Q2001 6-550-790-01 TRANSISTOR SSM6N15FE(TE85R)
 Q2101 6-551-631-01 TRANSISTOR RN1104MFV(TL3S
 Q2203 6-550-238-01 TRANSISTOR DTA114EMFS6T2L
 Q2301 6-551-631-01 TRANSISTOR RN1104MFV(TL3S
 Q2302 6-551-631-01 TRANSISTOR RN1104MFV(TL3S
 Q2401 6-551-202-01 TRANSISTOR LM6K1FS8T2R
 Q2402 6-551-202-01 TRANSISTOR LM6K1FS8T2R
 Q2403 6-550-119-01 TRANSISTOR DTC144EMFS6T2L
 Q2406 8-729-055-88 TRANSISTOR MCH3406-TL-E
(SLT-A33/A33L/A33Y)
 Q2407 8-729-055-88 TRANSISTOR MCH3406-TL-E
 Q2408 6-551-202-01 TRANSISTOR LM6K1FS8T2R
(SLT-A33/A33L/A33Y)
 Q2409 6-551-202-01 TRANSISTOR LM6K1FS8T2R
 Q3003 8-729-055-01 TRANSISTOR RN4984FE(TPLR3)
 Q3101 6-550-791-01 TRANSISTOR SSM3J15FV(TL3S
 Q3301 6-551-631-01 TRANSISTOR RN1104MFV(TL3S
* Q3303 6-552-123-01 TRANSISTOR ECH8652-S-TL-H
 Q3304 8-729-053-58 TRANSISTOR RN1904FE(TPLR3)
 Q3305 6-551-184-01 TRANSISTOR MCH6305-TL-E-S
 Q3307 6-550-789-01 TRANSISTOR SSM3K15FV(TL3S
 Q3602 8-729-053-57 TRANSISTOR RN1902FE(TPLR3)
 Q3803 6-550-576-01 TRANSISTOR SSM6E01TU
* Q3807 6-552-490-01 TRANSISTOR SCH1433-S-TL-H
 Q3808 6-551-630-01 TRANSISTOR RN1102MFV(TL3S
 Q3809 6-551-630-01 TRANSISTOR RN1102MFV(TL3S
 Q3810 6-551-374-01 TRANSISTOR SSM6N25TU
 Q3811 8-729-053-57 TRANSISTOR RN1902FE(TPLR3)
   <RESISTOR>
 R0004 1-218-977-11 METALCHIP 100K 5% 1/16W
 R0005 1-218-989-11 METALCHIP 1M 5% 1/16W
 R0011 1-218-929-11 METALCHIP 10 5% 1/16W
 R0013 1-208-927-11 METALCHIP 47K 0.5% 1/16W
 R0014 1-218-989-11 METALCHIP 1M 5% 1/16W
 R0015 1-218-929-11 METALCHIP 10 5% 1/16W
 R0016 1-218-959-11 METALCHIP 3.3K 5% 1/16W
 R0017 1-208-711-11 METALCHIP 15K 0.5% 1/16W
 R0018 1-220-802-11 METALCHIP 3.3 5% 1/16W
 R0020 1-208-927-11 METALCHIP 47K 0.5% 1/16W
 R0021 1-218-961-11 METALCHIP 4.7K 5% 1/16W
 R0022 1-208-715-11 METALCHIP 22K 0.5% 1/16W
 R0023 1-218-961-11 METALCHIP 4.7K 5% 1/16W
 R0024 1-208-931-11 METALCHIP 68K 0.5% 1/16W
 R0033 1-218-977-11 METALCHIP 100K 5% 1/16W
 R0034 1-218-941-81 METALCHIP 100 5% 1/16W
 R0037 1-208-911-11 METALCHIP 10K 0.5% 1/16W
 R0038 1-208-935-11 METALCHIP 100K 0.5% 1/16W
 R0056 1-208-943-11 METALCHIP 220K 0.5% 1/16W
 R0057 1-208-911-11 METALCHIP 10K 0.5% 1/16W
 R0063 1-220-874-81 METALCHIP 15 0.5% 1/16W
 R0070 1-218-985-11 METALCHIP 470K 5% 1/16W
 R0072 1-218-981-91 METALCHIP 220K 5% 1/16W
 R0110 1-218-990-81 SHORTCHIP 0
 R1010 1-218-965-11 METALCHIP 10K 5% 1/16W
 R1012 1-218-990-81 SHORTCHIP 0(SLT-A33/A33L/A33Y)
 R1015 1-218-965-11 METALCHIP 10K 5% 1/16W
(SLT-A55/A55V/A55L/A55VL/A55VY)
 R1105 1-218-977-11 METALCHIP 100K 5% 1/16W
 R1118 1-218-929-11 METALCHIP 10 5% 1/16W
 R1119 1-218-933-11 METALCHIP 22 5% 1/16W
 R1135 1-218-965-11 METALCHIP 10K 5% 1/16W
 R1140 1-218-953-11 METALCHIP 1K 5% 1/16W
 R1141 1-218-953-11 METALCHIP 1K 5% 1/16W
 R1144 1-208-699-11 METALCHIP 4.7K 0.5% 1/16W
 R1145 1-208-699-11 METALCHIP 4.7K 0.5% 1/16W
 R1148 1-218-953-11 METALCHIP 1K 5% 1/16W
 R1149 1-218-937-11 METALCHIP 47 5% 1/16W
 R1228 1-218-941-81 METALCHIP 100 5% 1/16W
 R1233 1-218-937-11 METALCHIP 47 5% 1/16W
 R1235 1-218-937-11 METALCHIP 47 5% 1/16W
 R1303 1-216-809-11 METALCHIP 100 5% 1/10W
 R1307 1-208-883-81 METALCHIP 680 0.5% 1/16W
 R1308 1-208-647-11 METALCHIP 33 0.5% 1/16W
 R1309 1-218-935-11 METALCHIP 33 5% 1/16W
 R1311 1-218-953-11 METALCHIP 1K 5% 1/16W
 R1319 1-218-953-11 METALCHIP 1K 5% 1/16W
 R1320 1-218-990-81 SHORTCHIP 0
 R1515 1-218-953-11 METALCHIP 1K 5% 1/16W
 R1801 1-218-977-11 METALCHIP 100K 5% 1/16W
 R1804 1-218-981-91 METALCHIP 220K 5% 1/16W
 R1806 1-218-961-11 METALCHIP 4.7K 5% 1/16W
 R1807 1-218-957-11 METALCHIP 2.2K 5% 1/16W
 R1808 1-218-977-11 METALCHIP 100K 5% 1/16W
 R1809 1-218-941-81 METALCHIP 100 5% 1/16W
 R1813 1-218-935-11 METALCHIP 33 5% 1/16W
 R1814 1-218-953-11 METALCHIP 1K 5% 1/16W
 R1815 1-218-953-11 METALCHIP 1K 5% 1/16W
 R1816 1-218-941-81 METALCHIP 100 5% 1/16W
 R1817 1-218-941-81 METALCHIP 100 5% 1/16W
 R1821 1-218-937-11 METALCHIP 47 5% 1/16W
 R1827 1-218-977-11 METALCHIP 100K 5% 1/16W
 R2003 1-208-885-11 METALCHIP 820 0.5% 1/16W
 R2004 1-208-859-81 METALCHIP 68 0.5% 1/16W
 R2005 1-218-970-11 METALCHIP 27K 5% 1/16W
 R2006 1-218-977-11 METALCHIP 100K 5% 1/16W
 R2123 1-216-800-11 METALCHIP 18 5% 1/10W
 R2125 1-218-953-11 METALCHIP 1K 5% 1/16W
 R2127 1-218-977-11 METALCHIP 100K 5% 1/16W
 R2129 1-218-945-11 METALCHIP 220 5% 1/16W
 R2130 1-218-945-11 METALCHIP 220 5% 1/16W
 R2209 1-218-965-11 METALCHIP 10K 5% 1/16W
 R2212 1-218-941-81 METALCHIP 100 5% 1/16W
 R2213 1-218-941-81 METALCHIP 100 5% 1/16W
 R2214 1-218-941-81 METALCHIP 100 5% 1/16W
 R2215 1-218-941-81 METALCHIP 100 5% 1/16W
 R2216 1-218-941-81 METALCHIP 100 5% 1/16W
 R2218 1-218-941-81 METALCHIP 100 5% 1/16W
 R2219 1-218-941-81 METALCHIP 100 5% 1/16W
 R2220 1-218-941-81 METALCHIP 100 5% 1/16W
Ref.No. PartNo. Description Ref.No. PartNo. Description Ref.No. PartNo. Description Ref.No. PartNo. Description
AM-022
