SLT-A33/A33L/A33Y/A55/A55V/A55L/A55VL/A55VY_L3
7-4
 R2221 1-218-941-81 METALCHIP 100 5% 1/16W
 R2222 1-218-941-81 METALCHIP 100 5% 1/16W
 R2223 1-218-941-81 METALCHIP 100 5% 1/16W
 R2225 1-218-941-81 METALCHIP 100 5% 1/16W
 R2226 1-218-941-81 METALCHIP 100 5% 1/16W
 R2229 1-218-945-11 METALCHIP 220 5% 1/16W
 R2231 1-218-989-11 METALCHIP 1M 5% 1/16W
 R2305 1-218-971-11 METALCHIP 33K 5% 1/16W
 R2306 1-218-965-11 METALCHIP 10K 5% 1/16W
 R2311 1-218-963-11 METALCHIP 6.8K 5% 1/16W
 R2312 1-218-963-11 METALCHIP 6.8K 5% 1/16W
 R2319 1-218-941-81 METALCHIP 100 5% 1/16W
 R2320 1-218-953-11 METALCHIP 1K 5% 1/16W
 R2321 1-218-941-81 METALCHIP 100 5% 1/16W
 R2322 1-218-953-11 METALCHIP 1K 5% 1/16W
 R2323 1-218-957-11 METALCHIP 2.2K 5% 1/16W
 R2324 1-218-957-11 METALCHIP 2.2K 5% 1/16W
 R2403 1-218-977-11 METALCHIP 100K 5% 1/16W
 R2404 1-218-977-11 METALCHIP 100K 5% 1/16W
 R2405 1-218-977-11 METALCHIP 100K 5% 1/16W
(SLT-A33/A33L/A33Y)
 R2406 1-218-977-11 METALCHIP 100K 5% 1/16W
 R2407 1-218-977-11 METALCHIP 100K 5% 1/16W
 R2410 1-218-953-11 METALCHIP 1K 5% 1/16W
(SLT-A33/A33L/A33Y)
 R2411 1-218-953-11 METALCHIP 1K 5% 1/16W
 R2413 1-218-937-11 METALCHIP 47 5% 1/16W
(SLT-A33/A33L/A33Y)
 R2414 1-218-937-11 METALCHIP 47 5% 1/16W
 R2416 1-218-941-81 METALCHIP 100 5% 1/16W
 R2419 1-218-941-81 METALCHIP 100 5% 1/16W
 R2420 1-218-990-81 SHORTCHIP 0
(SLT-A55/A55V/A55L/A55VL/A55VY)
 R2421 1-218-990-81 SHORTCHIP 0(SLT-A33/A33L/A33Y)
 R2425 1-218-990-81 SHORTCHIP 0(SLT-A33/A33L/A33Y)
 R2426 1-218-990-81 SHORTCHIP 0
(SLT-A55/A55V/A55L/A55VL/A55VY)
 R2429 1-218-990-81 SHORTCHIP 0(SLT-A33/A33L/A33Y)
 R2431 1-218-990-81 SHORTCHIP 0
 R3011 1-208-713-11 METALCHIP 18K 0.5% 1/16W
 R3012 1-208-911-11 METALCHIP 10K 0.5% 1/16W
 R3024 1-218-929-11 METALCHIP 10 5% 1/16W
 R3031 1-208-699-11 METALCHIP 4.7K 0.5% 1/16W
 R3032 1-218-990-81 SHORTCHIP 0
 R3033 1-218-990-81 SHORTCHIP 0
 R3034 1-218-990-81 SHORTCHIP 0
 R3035 1-218-990-81 SHORTCHIP 0
 R3041 1-218-990-81 SHORTCHIP 0
 R3042 1-218-990-81 SHORTCHIP 0
 R3043 1-218-990-81 SHORTCHIP 0
 R3055 1-218-965-11 METALCHIP 10K 5% 1/16W
 R3056 1-218-973-11 METALCHIP 47K 5% 1/16W
 R3057 1-218-990-81 SHORTCHIP 0
(SLT-A55/A55V/A55L/A55VL/A55VY)
 R3109 1-208-687-11 METALCHIP 1.5K 0.5% 1/16W
 R3110 1-218-949-11 METALCHIP 470 5% 1/16W
 R3115 1-218-990-81 SHORTCHIP 0
 R3117 1-218-945-11 METALCHIP 220 5% 1/16W
 R3205 1-218-951-11 METALCHIP 680 5% 1/16W
 R3206 1-218-989-11 METALCHIP 1M 5% 1/16W
 R3207 1-218-990-81 SHORTCHIP 0
 R3208 1-218-990-81 SHORTCHIP 0
 R3209 1-218-990-81 SHORTCHIP 0
 R3210 1-218-990-81 SHORTCHIP 0
 R3211 1-218-990-81 SHORTCHIP 0
 R3212 1-218-990-81 SHORTCHIP 0
 R3308 1-208-911-11 METALCHIP 10K 0.5% 1/16W
 R3309 1-208-935-11 METALCHIP 100K 0.5% 1/16W
 R3312 1-208-911-11 METALCHIP 10K 0.5% 1/16W
 R3313 1-208-911-11 METALCHIP 10K 0.5% 1/16W
 R3314 1-208-911-11 METALCHIP 10K 0.5% 1/16W
 R3315 1-208-911-11 METALCHIP 10K 0.5% 1/16W
 R3317 1-218-963-11 METALCHIP 6.8K 5% 1/16W
* R3320 1-248-319-11 RES-CHIP 0.47 1% 1/4W
* R3321 1-248-319-11 RES-CHIP 0.47 1% 1/4W
 R3323 1-218-963-11 METALCHIP 6.8K 5% 1/16W
 R3324 1-218-606-11 METALCHIP 2.2 5% 1W
 R3325 1-218-608-11 METALCHIP 3.3 5% 1W
 R3326 1-218-606-11 METALCHIP 2.2 5% 1W
 R3327 1-218-608-11 METALCHIP 3.3 5% 1W
 R3334 1-218-941-81 METALCHIP 100 5% 1/16W
 R3335 1-218-977-11 METALCHIP 100K 5% 1/16W
 R3611 1-218-959-11 METALCHIP 3.3K 5% 1/16W
 R3614 1-218-990-81 SHORTCHIP 0
 R3806 1-218-977-11 METALCHIP 100K 5% 1/16W
 R3807 1-218-961-11 METALCHIP 4.7K 5% 1/16W
 R3821 1-216-134-00 METALCHIP 2.2 5% 1/8W
 R3824 1-218-961-11 METALCHIP 4.7K 5% 1/16W
 R3827 1-218-977-11 METALCHIP 100K 5% 1/16W
 R3830 1-218-941-81 METALCHIP 100 5% 1/16W
 R3835 1-218-977-11 METALCHIP 100K 5% 1/16W
(SLT-A55/A55V/A55L/A55VL/A55VY)
 R3840 1-218-965-11 METALCHIP 10K 5% 1/16W
   <COMPOSITIONCIRCUITBLOCK>
 RB1101 1-234-378-21 RES,NETWORK 10K(1005X4)
 RB1102 1-234-378-21 RES,NETWORK 10K(1005X4)
 RB2001 1-234-376-11 RES,NETWORK 2.2K(1005X4)
 RB2002 1-234-375-21 RES,NETWORK 1K(1005X4)
 RB2101 1-234-377-21 RES,NETWORK 4.7K(1005X4)
 RB2102 1-234-377-21 RES,NETWORK 4.7K(1005X4)
 RB2301 1-234-382-21 RES,NETWORK 220K(1005X4)
 RB3001 1-234-380-21 RES,NETWORK 47K(1005X4)
 RB3002 1-234-382-21 RES,NETWORK 220K(1005X4)
 RB3003 1-234-375-21 RES,NETWORK 1K(1005X4)
 RB3004 1-234-380-21 RES,NETWORK 47K(1005X4)
 RB3005 1-234-378-21 RES,NETWORK 10K(1005X4)
 RB3006 1-234-375-21 RES,NETWORK 1K(1005X4)
 RB3101 1-234-375-21 RES,NETWORK 1K(1005X4)
 RB3102 1-234-375-21 RES,NETWORK 1K(1005X4)
 RB3201 1-234-378-21 RES,NETWORK 10K(1005X4)
 RB3202 1-234-381-11 RES,NETWORK 100K(1005X4)
* RB3203 1-234-384-11 RES,NETWORK 1M(1005X4)
 RB3204 1-234-381-11 RES,NETWORK 100K(1005X4)
 RB3301 1-234-381-11 RES,NETWORK 100K(1005X4)
 RB3401 1-234-370-21 RES,NETWORK 22(1005X4)
 RB3601 1-234-381-11 RES,NETWORK 100K(1005X4)
 RB3802 1-234-375-21 RES,NETWORK 1K(1005X4)
 RB3804 1-234-381-11 RES,NETWORK 100K(1005X4)
   <SENSOR>
* SE2101 1-487-118-11 GMRSENSOR
 SE2501 1-489-146-11 DIGITALACCELEROMETER(ADXL345)
   <VARISTOR>
* VD3801 1-802-128-11 VARISTOR(SMD)
   <VIBRATOR>
* X1301 1-813-403-81 QUARTZCRYSTALOSCILLATOR(12MHz)
 X3001 1-795-244-11 VIBRATOR,CERAMIC(10MHz)
 X3101 1-781-525-11 VIBRATOR,CRYSTAL(32.768kMz)
 X3201 1-781-646-21 VIBRATOR,CERAMIC(4MHz)
  A-1783-996-A BT-062FLEXIBLEBOARD,COMPLETE
   **********************
(TH7201isnotsupplied,butthisisincludedinBT-062flexiblecompleteboard.)
   <BATTERYTERMINALBOARD>
0BT901 1-780-858-11 TERMINALBOARDBATTERY
  1-881-176-21 GY-024FLEXIBLEBOARD
   ********************
(BT900(lithiumbattery)isnotincludedinGY-024flexibleboard.)
(Allmountedpartsarenotsupplied,buttheyareincludedinGY-024flexibleboard.)
   <BATTERY>
0BT900 1-756-135-31 BATTERYLITHIUMSECONDARY(Note1)(Caution)
  A-1790-017-A IMIMAGERUNIT16M(Note2)
(SLT-A55/A55V/A55L/A55VL/A55VY)
  (Notsupplied) IS-073BOARD,COMPLETE
(SLT-A55/A55V/A55L/A55VL/A55VY)
   *********************
(IS-073completeboardandallmountedparts(includingIC4501(CMOSimager))are
notsupplied,buttheyareincludedinIMimagerunit16M.)
  A-1773-801-A IMIMAGERUNIT14M(Note2)(SLT-A33/A33L/A33Y)
  (Notsupplied) IS-077BOARD,COMPLETE(SLT-A33/A33L/A33Y)
   *********************
(IS-077completeboardandallmountedparts(includingCP001(CMOSimager))are
notsupplied,buttheyareincludedinIMimagerunit14M.)
  1-880-877-11 ISL-001FLEXIBLEBOARD
   ********************
  1-880-878-11 ISP-001FLEXIBLEBOARD
   ********************
  1-880-883-11 LCD-021FLEXIBLEBOARD
   *********************
  A-1781-920-A PD-414BOARD,COMPLETE
   **********************
   <CAPACITOR>
 C6001 1-125-777-11 CERAMICCHIP 0.1uF 10% 10V
 C6002 1-100-415-91 CERAMICCHIP 0.47uF 10% 6.3V
 C6003 1-165-989-11 CERAMICCHIP 10uF 10% 6.3V
 C6004 1-125-777-11 CERAMICCHIP 0.1uF 10% 10V
 C6005 1-125-777-11 CERAMICCHIP 0.1uF 10% 10V
 C6006 1-125-777-11 CERAMICCHIP 0.1uF 10% 10V
 C6007 1-100-567-81 CERAMICCHIP 0.01uF 10% 25V
 C6008 1-112-300-91 CERAMICCHIP 4.7uF 10% 10V
 C6009 1-112-717-91 CERAMICCHIP 1uF 10% 6.3V
 C6010 1-100-415-91 CERAMICCHIP 0.47uF 10% 6.3V
 C6011 1-165-908-11 CERAMICCHIP 1uF 10% 10V
* C6012 1-112-746-11 CERAMICCHIP 4.7uF 10% 6.3V
 C6013 1-112-300-91 CERAMICCHIP 4.7uF 10% 10V
* C6014 1-112-746-11 CERAMICCHIP 4.7uF 10% 6.3V
 C6015 1-112-021-91 CERAMICCHIP 2.2uF 20% 16V
 C6016 1-165-884-11 CERAMICCHIP 2.2uF 10% 6.3V
* C6017 1-112-746-11 CERAMICCHIP 4.7uF 10% 6.3V
 C6020 1-165-908-11 CERAMICCHIP 1uF 10% 10V
 C6021 1-165-908-11 CERAMICCHIP 1uF 10% 10V
 C6023 1-100-696-91 CERAMICCHIP 1uF 10% 6.3V
 C6024 1-164-933-11 CERAMICCHIP 220PF 10% 50V
   <CONNECTOR>
 CN6001 1-816-654-61 FFC/FPCCONNECTOR(LIF)6P
* CN6002 1-817-830-71 CONNECTOR,FPC(ZIF)33P
* CN6003 1-822-038-81 CONNECTOR,FPC(ZIF)61P
   <DIODE>
 D6001 8-719-069-29 DIODERB520S-30FJTE61
   <IC>
* IC6001 6-712-051-01 ICSN65LVDS302ZQER
   <COIL>
 L6001 1-400-588-11 INDUCTOR 10uH
* L6002 1-481-642-11 INDUCTOR 10uH
   <RESISTOR>
 R6002 1-208-695-11 METALCHIP 3.3K 0.5% 1/16W
 R6019 1-218-953-11 METALCHIP 1K 5% 1/16W
 R6022 1-218-961-11 METALCHIP 4.7K 5% 1/16W
 R6023 1-218-961-11 METALCHIP 4.7K 5% 1/16W
 R6024 1-218-961-11 METALCHIP 4.7K 5% 1/16W
 R6025 1-208-663-11 METALCHIP 150 0.5% 1/16W
  A-1783-997-A RM-099FLEXIBLEBOARD,COMPLETE
   ******************************
(Allmountedpartsarenotsupplied,buttheyareincludedinRM-099flexiblecomplete
board.)
  1-881-235-21 SHD-002FLEXIBLEBOARD
   *********************
(Allmountedpartsarenotsupplied,buttheyareincludedinSHD-002flexibleboard.)
  A-1783-998-A SHM-001FLEXIBLEBOARD,COMPLETE
   *******************************
(Allmountedparts(exceptMIC901andMIC902)arenotsuppliedbuttheyareincluded
inSHM-001flexiblecompleteboard.)
   <MICROPHONE>
 MIC901 1-542-757-61 MICROPHONEUNIT
 MIC902 1-542-757-61 MICROPHONEUNIT
  A-1779-676-A MBSHUTTERCHARGEUNIT
  (Notsupplied) SLK-008FLEXIBLEBOARD,COMPLETE
   *******************************
(SLK-008flexiblecompleteboardandM903arenotsupplied,buttheyareincludedin
MBshutterchargeunit.)
Ref.No. PartNo. DescriptionRef.No. PartNo. DescriptionRef.No. PartNo. DescriptionRef.No. PartNo. Description
RM-099AM-022 IS-077 SHM-001SHD-002PD-414LCD-021ISP-001ISL-001IS-073GY-024BT-062 SLK-008
