Sony SLT-A55 - AF-131 FLEXIBLE BOARD LAYOUT; BT-062 FLEXIBLE BOARD LAYOUT

SLT-A33/A33L/A33Y/A55/A55V/A55L/A55VL/A55VY_L3
6-42
TH7201
LN7201
LN7204 LN7203 LN7202
1-881-027- 11
BT-062 FLEXIBLE BOARD
29
Note: TH7201 is not supplied, but this is included in BT-062 flexible complete board.
BT901
BATTERY TERMINAL
BOARD
( )
1 22
: Uses unleaded solder.
28
1
15 14
LN8001
IC8001
118
AF-131 FLEXIBLE BOARD
29
1-880-885- 11
Note: AF-131 flexible complete board and IC8001 are not supplied,
but they are included in ALX-8630 (AF module).
