SPECIFICATIONS
DIMENSIONS
1 5/8 (41)
7/8 (22)
ø2 3/4 (70)
2 3/8 (61)
3 3/4 (95)
2 1/4 (57) 11/16 (17)
4 1/16 (103) 13/16 (20)
Unit: inches (mm)
SNC-CX600W
Camera
Image Sensor 1/4-type progressive scan Exmor CMOS sensor
Number of Effective Pixels Approx. 1.3 Megapixels
Minimum Illumination (50 IRE) Color: 1.0 lx (F2.0, VE OFF, AGC MAX, 1/30 s, 30 fps)
Minimum Illumination (30 IRE) Color: 0.5 lx (F2.0, VE OFF, AGC MAX, 1/30 s, 30 fps)
Dynamic Range More than 60 dB
Gain Auto
Shutter Speed 1/1 s to 1/10,000 s
Exposure Control Exposure compensation, AGC, Shutter speed
White Balance ATW, ATW-PRO, Fluorescent lamp, Mercury lamp, Sodium vapour
lamp, Metal halide lamp, White LED, One push WB, Manual
Lens Fixed lens
Horizontal Viewing Angle 120°
Vertical Viewing Angle 64.0°
Focal Length f = 1.83 mm
F-Number F2.0
Minimum Object Distance 500 mm
White-light LED Illuminator Yes
LED Working Distance 3 m
Camera Features
Wide-D View-DR LT-C
Tone Correction Visibility Enhancer (VE)
Noise Reduction XDNR Technology
Image Stabilizer Yes
Picture Mode Yes
Privacy Masking (number) 20
Privacy Masking (shape) Quadrangle formed by any four corner points
Privacy Masking (color/effect) Opaque 14 colors (Black, White, Red, Green, Blue, Cyan, Yellow,
Magenta, Gray (6 scales)), Mosaic
Edge Storage Yes
Memory Size for Pre/Post Buffer Approx. 8 MB
Compatibility with Cloud Service Yes
Voice Alert Yes
Superimpose Number 3 independent positions for characters (Codec, Date & Time,
Event, Text (Max. 64 characters)), 1 independent position for logo
marks
Superimpose Language English
Menu Language English, Japanese, Chinese (simplified), Chinese (traditional),
French, Spanish, German, Italian, Korean, Portuguese, Russian,
Arabic, Hindi, Vietnamese, Thai
Smartphone viewer Yes
Video
Resolution 1280 x 720, 1024 x 576, 720 x 576
720 x 480, 704 x 576, 640 x 480, 640 x 360, 352 x 288, 320 x 180
(H.264, JPEG)
Compression Format H.264 (High/Main/Baseline Profile), JPEG
Maximum Frame Rate H.264: 30 fps (1280 x 720)
JPEG: 30 fps (1280 x 720)
Bitrate Compression Mode CBR/VBR (selectable)
Range of Bitrate Setting 64 Kbps to 8 Mbps
Solid PTZ Yes
Bandwidth Control JPEG
Multi Streaming Capability Triple streaming
Number of Clients 5
Intelligent Video Analytics
Analytics Architecture DEPA Advanced
Intelligent Motion Detection Yes
Face Detection Yes
Tamper Alarm Yes
Scene Analytics Passing, Intrusion, Left Object Detection, Removed Object
Detection
Audio
Compression Format G.711/G.726/AAC (16 kHz, 48 kHz)
System Requirements
Operating System Windows
®
XP
®
(32 bit) Professional Edition
Windows
®
Vista
®
(32 bit) Ultimate, Business Edition
Windows
®
7 (32/64 bit) Ultimate, Professional Edition
Windows
®
8 Pro (32/64 bit)
Microsoft
®
DirectX 9.0c or higher
Processor Intel Core2 CPU 6420 2.13 GHz or higher
Memory 2 GB or more
Web Browser Microsoft
®
Internet Explorer
®
Ver. 7.0, Ver. 8.0, Ver. 9.0, Ver 10.0
Firefox
®
Ver. 19.02 (plug-in free viewer only)
Safari
®
Ver. 5.1 (plug-in free viewer only)
Google Chrome
®
Ver. 25.0 (plug-in free viewer only)
SNC-CX600W
Network
Protocols IPv4, TCP, UDP, ARP, ICMP, IGMP*, HTTP, DHCP, DNS, NTP, RTP/RTCP,
RTSP over TCP, RTSP over HTTP, SMTP, IPv6, HTTPS, SNMP (v1, v2c, v3),
SSL
QoS DSCP, Wi-Fi Multimedia
Multicast Streaming Support Yes
ONVIF Conformance Profile S
Wireless Network IEEE802.11b/g/n
Wi-Fi Certified Yes
Wi-Fi Protected Setup Yes (WPS)
Authenticatoin Wireless: No, Wired: IEEE802.1X
Interface
Microphone Input Built-in microphone
Line Output Built-in speaker
Network Port 10BASE-T/100BASE-TX (RJ-45)
Card Slots micro SD
Confirmed SD Card Type SDHC (no support for SDXC)
General
Power Requirements DC 5 V
Power Consumption 5.0 W max.
Operating Temperature Wired: 32°F to 122°F (0°C to 50°C)
Wireless: 32°F to 104°F (0°C to 40°C)
Storage Temperature -4°F to +140°F (-20°C to +60°C)
Operating Humidity 20% to 80%
Storage Humidity 20% to 95%
Dimensions (W x H x D) Approx. 2 13/32 inches x 3 3/4 inches x 1 5/8 inches
(61 mm x 95 mm x 41 mm)
Weight Approx. 3.9 oz (110 g)
External Material PC (polycarbonate)
External Color White
Fire Retardant UL94HB or higher
Safety Regulations JATE, UL2044, IEC60950-1, VCCI Class B, FCC Class B, IC Class B,
EN55022 (Class B) + EN50130-4, EN55022 (Class B) + EN55024,
EN60950-1 EN62311, EN300 328 EN301489-17 EN301489-1,
AS/NZS CISPR22 (Class B), AS/NZS 4286, GB4943,
(IEC60950) + GB9254 (CISPR22), SRRC, CNS14336 (IEC60950-1) +
CNS13438 (CISPR22), RCM, Russia EAC, KCC
Supplied Accessories Wi-Fi module (1)
AC adapter (1)
Power code (1)
Camera stand (1)
Screws (3)
Installation Manual (1)
Quick start guide (1)
Warranty card (1)
Safety regulations for network camera (1)
Safety regulations for USB wireless LAN module (1)
* SSM (Source Specific Multimedia) is supported.
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
sony.com/security
S-IP2171 (MK11060V1)
Printed in USA (9/13)
