– 3 –
2. French Model Addition
French model is almost the same as AEP model.
As only the difference from AEP model is described in this manual, please refer to SRF-S50 service manual (9-959-780-∏)
previously issued for other information.
AEP Model French Model
Ref. No. Part No. Description Remark
R101 1-216-081-00 METAL CHIP 22K 5% 1/10W
R102 1-216-081-00 METAL CHIP 22K 5% 1/10W
Ref. No. Part No. Description Remark
• Difference Table
! : Indicates different portion.
JC10 1-216-295-00 SHORT 0
JC11 1-216-295-00 SHORT 0
Location C-4 to E-6
Location C-7 to E-9
@
#
!
#
To Next Page
