Sony SRS-D101 - Section 2 Diagrams

4
SRS-D101
SECTION 2
DIAGRAMS
• IC Block Diagrams
IC301 LA4601N
10
7
9
8
6 5
1
2
4
3
R-IN
PRE-GND
L-IN
STBY
Standby switching
CH1 input
amplifier
CH2 input
amplifier
REF
amplifier
Predrive
amplifier
Predrive
amplifier
TSD protector
Output
amplifier
Output
amplifier
FILTERP. P
POWER
GND
R-OUT
L-OUT
Vcc
Pop noise prevention block
Ripple filter
IC302 LM4701T
