EXPLODED VIEW AND PARTS LIST
NOTE:
• -XX, -X mean standardized parts, so they may
have some differences from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• The mechanical parts with no reference number
in the exploded views are not supplied.
R-CH
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
1 X-4952-727-1 NET ASSY, SPEAKER
2 4-217-353-01 PANEL(WOOFER)
3 4-874-614-11 SCREW(4) (3.5X14), TAPPING
4 4-218-202-01 CATCHER, NET
5 4-217-365-01 BOX(L), SPEAKER (L-CH)
5 4-217-366-01 BOX(R), SPEAKER (R-CH)
6 4-870-003-00 CLIPPER, CODE
7 A-4412-189-A PANEL ASSY, TWEETER
SP1 1-529-727-11 SPEAKER (12cm) (WOOFER)
SP2 1-529-476-11 SPEAKER (2.5cm) (TWEETER)
SP1
SP2
1
3
5
7
6
4
not supplied
not supplied
3
2
not
supplied
