SS-CNP7M/MSP2M/MSP3M/MSP7M/SRP7M
2
SECTION 1
DISASSEMBLY
Note: Follow the disassembly procedure in the numerical order given.
1-1. OVERALL ASSY (SS-MSP7M)
1
Insert the jig (J-2501-238-A) into a space
and raise the front panel assy gradually.
Note: When using a jig, please work so as not to injure
front panel and speaker cabinet.
2
front panel assy
To Next Page
