Audio/Video Receiver
For more information:
http://www.sony.com/dn
STR-DE697
Features
Amplifier Section
• Black Finish A/V Receiver
• 7 Channel Power Rating 100 Watts
Per Channel x 7 (8 ohms 1 kHz,
THD 0.7%)
• Stereo Power Rating 100 Watts
Per Channel x 2 (8 ohms 20 Hz-20
kHz, THD .09%)
• Dolby® Digital, Dolby® Digital EX,
dts®, 96k/24 bit dts ES®, Dolby®
Pro Logic® II Decoding
• A & B / A or B Speaker Switch
• 32-bit Dolby® Digital, Dolby® Pro
Logic® and dts® decoder
• 32-bit DSP with 11 Acoustic
Environments
• Digital Cinema Sound™ System
with Cinema Studio EX Modes
• Sound Field Modes (Movie, Music,
AFD, 2 Channel): Movie: 3 Modes;
Music: 3 Modes; AFD: 4 Modes; 2
Channel: 1 Mode
• Station Presets 30 Total
• Circuit Device (Discrete)
• Sound Field Link
Inputs and Outputs
• 2 Component Video Inputs HD
Pass 80 MHz
• Screw Terminals/Terminals for A &
B Speaker Connections
• Multi-Channel IN (Analog) 5.1
Channel
• Headphone Jack 1/4" Jack
• Control A 1 II
• Analog Audio Input x 3
• Analog Audio Output x 1
• Digital Audio Input x 5 (3 Optical, 2
Coaxial)
• Optical Audio Output x 1
• Pre-Out x 1 (Subwoofer)
• Composite Video Input x 4
• Composite Video Output x 1
• S-Video Input x 3
• S-Video Output x 1
• Component Video Input x 2 (HD
Pass 80 MHz)
• Component Video Output x 1 (HD
Pass 80 MHz)
• Monitor Out x 2 (1 Composite, 1
S-Video)
• AC Outlet (switched) x 1
Convenience
• Pre-Programmed Remote Control
Specifications
Video
• Component Video (Y/Pb/Pr) Input
Sensitivity Impedance 1 Vp-p/75
ohm
• S-Video (Y)/(C) Input Sensitivity
Impedance (Y) 1 Vp-p/75 ohm;
(C) .286 Vp-p/75 ohm
• Component Video (Y/Pb/Pr) Input
Sensitivity Impedance (Y) 1
Vp-p/75 ohm;
(Pb) .7 Vp-p/75 ohm;
(Pr) .7 Vp-p/75 ohm
• Component Video (Y/Pb/Pr) Input
Sensitivity Impedance 1 Vp-p/75
ohm
• Composite Video Input
Sensitivity/Impedance (Y) 1
Vp-p/75 ohm;
(C) .286 Vp-p/75 ohm
• S-Video (Y)/(C) Output Sensitivity
Impedance (Y)1 Vp-p/75 ohm; (C)
.286 Vp-p/75 ohm
• Component Video (Y/Pb/Pr)
Output Sensitivity Impedance (Y) 1
Vp-p/75 ohm;
(Pb) .7 Vp-p/75 ohm;
(Pr) .7 Vp-p/75 ohm
Amplifier Section
• Channel Power Rating 7 Channel
Power Rating: 100 Watts Per
Channel x7 (8ohms 1 kHz, THD
0.7%)
• Output Level and Impedance
Display Type (8 Seg.)
• Line Input S/N Ratio 96 dB
• Frequency Response Line (CD) 10
Hz -70kHz +.5 dB /-2 dB
• Line (CD) Input Sensitivity
Impedance 500mV/50 k ohm
• Subwoofer Pre-Out Level
Impedance 2V/1 k ohm
• Record Out Level/Impedance
500mV/10 k ohm
General
• Power Requirements 120V AC , 60
Hz
• Power Consumption n/a
• Power Consumption (Standby) n/a
Supplied Accessories
• Instruction Manual
• Remote Model: RM-PP413
Weights & Measures
• n/a
• n/a
UPC Codes
• 0272426441990
