Additional Information
AM tuner section
Tuning range
Models of area code E
With 10-kHz tuning scale: 530 – 1610 kHz
6)
With 9-kHz tuning scale: 531 – 1602 kHz
6)
Models of area code CN, CEL
With 9-kHz tuning scale: 531 – 1602 kHz
Antenna Loop antenna
Usable sensitivity 50 dB/m (at 1,000 kHz or
999 kHz)
S/N 54 dB (at 50 mV/m)
Harmonic distortion 0.5 % (50 mV/m,
400 Hz)
Selectivity
At 9 kHz: 35 dB
At 10 kHz: 40 dB
6) You can change the AM tuning scale to 9 kHz or
10 kHz. After tuning in any AM station, turn off
the receiver. Hold down TUNING + and press
?/1. All preset stations will be erased when you
change the tuning scale. To reset the scale to
10 kHz (or 9 kHz), repeat the procedure.
Video section
Inputs
Video: 1 Vp-p, 75 ohms
S-video: Y: 1 Vp-p, 75 ohms
C: 0.286 Vp-p, 75 ohms
Outputs
Video: 1 Vp-p, 75 ohms
S-video: Y: 1 Vp-p, 75 ohms
C: 0.286 Vp-p, 75 ohms
Remote control
Remote control system
Infrared control
Power requirements 4.5 V DC with three LR6
(size-AA) alkaline
batteries
Dimensions 175 × 62 × 33 mm
Mass (approx.) 135 g excluding batteries
General
Power requirements
Area code Power requirements
CEL 230 V AC, 50/60 Hz
CN 220 – 230 V AC, 50/60 Hz
E 120/220/240 V AC, 50/60 Hz
Power consumption
Area code Power consumption
CN, CEL 390 W
E 400 W
Power consumption (during standby mode)
1 W
AC outlets
Area code AC outlets
CEL 1 switched, 100 W MAX
E 2 switched, 100 W MAX
Dimensions 430 × 175 × 465 mm
including projecting parts
and controls
Mass (Approx.) 20.0 kg
Supplied accessories
FM wire antenna (1)
AM loop antenna (1)
Remote commander RM-LJ305 (1)
LR6 (size-AA) batteries (3)
For details on the area code of the component you
are using, see page 2.
Design and specifications are subject to change
without notice.
