Sensitivity
jngeaenee
SIN
eee
fuente
2.5
mV
s0kohms
|
5258,
A
TAPE
1,2
150
mV
|
50k
ohms
Baal
‘a
Hox
|
150
mV
50
k
ohms
pee
a
*
°78
IHF
Measured
with
rated
output
power
into
8-ohm
loads
(both
channels
driven
simultaneously)
at
1 kHz
Outputs
(with
rated
input)
REC OUT i, 2
Voltage 150 mV, Impedance 4.7 k ohms
Any low and high impedance
HEADPHONES headphones are recommended.
SPEAKER A, B Any speakers of 8 - 160hms
are recommended.
Frequency response PHONO: RIAA equalization curve +0.5 dB
AUX, TAPE 1,2: 5Hz-90kHz +9dB
BASS: +8dB at 100 Hz
TREBLE: =+8dB at 10 kHz
Loudness control (att. 30 dB)
+8qdB at 50Hz, +2dB at 10 kHz
12 dBloctave attenuation below 15 Hz
Tone controls
Subsonic filter
FM tuner section
Tuning range
Antenna terminals
87.5 - 108 MHz
300 ohms, balanced
75 ohms, unbalanced
Intermediate
frequency
10.7
MHz
Sensitivity at 50 dB quieting
17.3 dBf, 4uV (mono)
36.8 dBf, 38zV (stereo)
Usable
sensitivity
11.2
dBf,
IHF
2uV
Signal-to-noise
ratio
83
dB
(mono),
78
dB
(stereo)
Harmonic
distortion
0.08%
(mono),
0.2%
(stereo)
at
100
Hz
0.08% (mono), 0.15% (stereo) at 1 kHz
0.1% (mono), 0.2% (stereo) at 6 KHz
40 dB at 100 Hz
45 dB at 1 kHz
40 dB at 6 kHz
Separation
Frequency response 30 Hz - 15 kHz +2 dB
Alternate channel selectivity 80 dB (400 kHz)
Capture ratio 1.0dB
AM suppression ratio 54dB
Image response ratio 85dB
IF response ratio 100 dB
Spurious response ratio 95dB
RF intermodulation 65dB
Sub-carrier product ratio 45dB
Muting threshold Approx. 20 dBf, 5.5uV
Auto tuning level LOW: 20dBf
MID: 40 dBf
HIGH: 60 dBf
AWM tuner section
Tuning range
Antenna
530 KHz - 1,610 kHz (522 kHz - 1,602 kHz)
Ferrite-bar antenna :
External antenna terminal
Intermediate frequency 450 kHz
Usable sensitivity 300,V/m, ferrite-bar antenna
100 nV, external antenna
at 1,000 kHz
Signal-to-noise ratio 54dB at 50 mV/m
Harmonic distortion 0.5% at 50 mV/m, 400 Hz
H
i
Selectivity 40 dB at 10 kHz
General
System Tuner section: PLL quartz-locked digital
synthesizer system
Equalizer amp section: {C op-amp, NF type
Tone amp section: NF type
Power amp section: Pure-complementary —
DC amp
Power requirements US, Canadian model: 120 V ac, 60 Hz
E model: 110, 120, 220, 240 V ac
50/60 Hz
Power consumption USA model: 110W
Canadian model: 180W
AC outlets 1 switched 80 W, 1 unswitched 300 W
Dimensions Approx. 430 105x375 mm (wi/h/d)
(17 x 44/4 x 147s inches)
including projecting parts and controls
Weight Approx. 7.6 kg (16 |b 13 oz) net
Approx. 8.6 kg (19 1b) in shipping carton
