– 36 –
! 21 1-574-805-11 CORD, POWER (EA,MY,SP,HK,AR)
! 21 1-575-653-11 CORD, POWER (E,JE)
! 21 1-575-975-11 CORD, POWER (US,CND)
! 21 1-690-608-11 CORD, POWER (AUS)
! 21 1-751-326-31 CORD, POWER (TH)
! 22 1-569-007-11 ADAPTER, CONVERSION 2P (E3,JE)
! 22 1-569-008-11 ADAPTER, CONVERSION 2P (EA,MY,SP)
! 22 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
* 23 4-980-659-01 PLATE, JACK (US)
* 23 4-980-659-11 PLATE, JACK (CND)
* 23 4-980-659-21 PLATE, JACK (E,EA,AR,JE)
* 23 4-980-659-31 PLATE, JACK (AUS)
* 23 4-980-659-41 PLATE, JACK (HK)
* 23 4-980-659-51 PLATE, JACK (MY,SP)
* 23 4-980-659-71 PLATE, JACK (TH)
24 4-909-982-11 SCREW, TAPPING
* 25 3-701-946-15 LABEL, FUSE RATING (3.15A/250V) (US,CND)
* 25 3-701-946-14 LABEL, FUSE RATING (2.5A/250V)(US)
E801 4-942-204-01 PLATE, GROUND
! F851 1-532-388-51 FUSE, TIME LAG (T2AL) (TH,AUS)
! F851 1-532-504-51 FUSE, TIME LAG (T4AL)
(EXCEPT US,CND,TH,AUS)
! F851 1-576-109-11 FUSE (5A/125V) (CND)
! F851 1-576-110-11 FUSE (6A/125V) (US)
! F852 1-532-388-51 FUSE, TIME LAG (T4AL) (E,EA,MY,SP,HK,AR,JE)
! F853 1-532-465-51 FUSE, TIME LAG (T3.15AL) (EXCEPT US,CND)
! F853 1-576-107-11 FUSE (3.15A/250V) (US,CND)
! F854 1-532-465-51 FUSE, TIME LAG (T3.15AL) (EXCEPT US,CND)
! F854 1-576-107-11 FUSE (3.15A/250V) (US,CND)
! F855 1-532-465-51 FUSE, TIME LAG (T3.15AL) (EXCEPT US,CND)
! F855 1-532-781-41 FUSE, MICRO (3.15A) (US)
! F855 1-576-107-11 FUSE (3.15A/250V) (CND)
! F856 1-532-465-51 FUSE, TIME LAG (T3.15AL) (EXCEPT US,CND)
! F856 1-576-107-11 FUSE (3.15A/250V) (CND)
! S851 1-572-367-11 SWITCH, VOLTAGE SELECTOR
(E,EA,MY,SP,HK,AR,JE)
M601 1-698-651-11 FAN, DC (TH)
M601 1-698-792-11 FAN, DC (EXCEPT TH)
! T801 1-429-533-11 TRANSFORMER, POWER (US,CND)
! T801 1-429-534-11 TRANSFORMER, POWER (EXCEPT US,CND)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
1 4-978-037-11 KNOB (M)
* 2 3-703-244-00 BUSHING (2104), CORD (EXCEPT E, TH, JE)
2 3-703-571-11 BUSHING (S) (4516), CORD (TH)
2 4-966-266-01 BUSHING (S) (FBS002), CORD (E,JE)
* 3 1-660-120-11 CONNECTION BOARD
* 4 A-4389-758-A POWER (B) BOARD, COMPLETE (US)
* 4 A-4390-467-A POWER (B) BOARD, COMPLETE (CND)
* 4 A-4390-470-A POWER (B) BOARD, COMPLETE
(E,EA,HK,AR,AUS,JE)
* 4 A-4390-473-A POWER (B) BOARD, COMPLETE (MY)
* 4 A-4390-476-A POWER (B) BOARD, COMPLETE (SP)
* 4 A-4390-768-A POWER (B) BOARD, COMPLETE (TH)
* 5 A-4389-757-A POWER (A) BOARD, COMPLETE (US)
* 5 A-4390-466-A POWER (A) BOARD, COMPLETE (CND)
* 5 A-4390-469-A POWER (A) BOARD, COMPLETE
(E,EA,HK,AR,AUS,JE)
* 5 A-4390-472-A POWER (A) BOARD, COMPLETE (MY)
* 5 A-4390-475-A POWER (A) BOARD, COMPLETE (SP)
* 5 A-4390-767-A POWER (A) BOARD, COMPLETE (TH)
6 3-704-366-01 SCREW (CASE) (M3X8)
7 4-979-348-71 CASE (EXCEPT MY,SP)
7 4-979-348-91 CASE (MY,SP)
8 1-533-293-11 FUSE HOLDER
* 9 1-660-119-11 TRANSFORMER SECONDARY BOARD
* 10 1-658-764-11 TRANS (A) BOARD
* 11 4-949-235-01 HOOK
* 12 1-660-122-11 SP BOARD
* 13 A-4389-756-A MAIN BOARD, COMPLETE (US)
* 13 A-4390-465-A MAIN BOARD, COMPLETE (CND)
* 13 A-4390-468-A MAIN BOARD, COMPLETE (E,EA,HK,AR,AUS,JE)
* 13 A-4390-471-A MAIN BOARD, COMPLETE (MY)
* 13 A-4390-474-A MAIN BOARD, COMPLETE (SP)
* 13 A-4390-766-A MAIN BOARD, COMPLETE (TH)
14 A-4303-547-A TCB BOARD, COMPLETE (US,CND)
14 A-4303-499-A TCB BOARD, COMPLETE (E3,EA,MY,SP,HK)
14 A-4303-526-A TCB BOARD, COMPLETE (E2,AR,AUS)
14 A-4303-528-A TCB BOARD, COMPLETE (JE)
14 A-4304-992-A TCB BOARD, COMPLETE (TH)
* 15 1-659-506-11 VOLTAGE SW BOARD (E,EA,MY,SP,HK,AR,JE)
* 16 1-660-121-11 SENSOR BOARD
* 18 4-880-403-11 HEAT SINK
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
