– 43 –
R1003 1-249-423-11 CARBON 3.3K 5% 1/4W
R1005 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1006 1-216-065-00 METAL GLAZE 4.7K 5% 1/10W
R1007 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R1010 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R1011 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R1020 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R1021 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R1061 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R1101 1-249-437-11 CARBON 47K 5% 1/4W
R1102 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R2001 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R2002 1-249-441-11 CARBON 100K 5% 1/4W
R2003 1-216-077-00 METAL CHIP 15K 5% 1/10W
R2004 1-216-073-00 METAL CHIP 10K 5% 1/10W
R2005 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R2006 1-249-417-11 CARBON 1K 5% 1/4W
R2007 1-249-425-11 CARBON 4.7K 5% 1/4W
R2008 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R2010 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R2011 1-249-409-11 CARBON 220 5% 1/4W
R2012 1-249-409-11 CARBON 220 5% 1/4W
R2030 1-216-457-00 METAL OXIDE 1.2K 5% 2W
(US,CND)
R2030 1-216-456-00 METAL OXIDE 820 5% 2W
(EXCEPT US,CND)
R2051 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R2052 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R2053 1-216-073-00 METAL CHIP 10K 5% 1/10W
R2054 1-216-073-00 METAL CHIP 10K 5% 1/10W
R2055 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R2056 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R2057 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R2058 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R2060 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R2061 1-249-409-11 CARBON 220 5% 1/4W
R2062 1-249-409-11 CARBON 220 5% 1/4W
R2101 1-249-437-11 CARBON 47K 5% 1/4W
R2102 1-249-437-11 CARBON 47K 5% 1/4W
R3000 1-247-903-00 CARBON 1M 5% 1/4W
R3001 1-249-411-11 CARBON 330 5% 1/4W
R3002 1-249-432-11 CARBON 18K 5% 1/4W
R3006 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R3007 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R3008 1-249-417-11 CARBON 1K 5% 1/4W
R3009 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R3010 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R3030 1-249-417-11 CARBON 1K 5% 1/4W
R3040 1-249-417-11 CARBON 1K 5% 1/4W
R3100 1-247-807-31 CARBON 100 5% 1/4W
R3107 1-249-441-11 CARBON 100K 5% 1/4W
R3207 1-249-441-11 CARBON 100K 5% 1/4W
R5032 1-249-429-11 CARBON 10K 5% 1/4W
(E2,AUS)
< VARIABLE RESISTOR >
RV771 1-223-672-11 RES, VAR, CARBON 10K (MIC LEVEL)
< RELAY >
RY801 1-515-920-11 RELAY (24V)
RY2001 1-515-920-11 RELAY (24V)
< TERMINAL >
TB901 1-537-240-31 TERMINAL BOARD (CHECKER PIN)
(FRONT SPEAKER)
< VIBRATOR >
X3001 1-579-952-21 VIBRATOR, CERAMIC (8MHz)
************************************************************
* A-4389-762-A PANEL BOARD, COMPLETE (US,CND)
* A-4389-767-A PANEL BOARD, COMPLETE (E3,EA,MY,SP,HK)
* A-4389-768-A PANEL BOARD, COMPLETE (E2)
* A-4390-477-A PANEL BOARD, COMPLETE (AR)
* A-4390-479-A PANEL BOARD, COMPLETE (AUS)
* A-4390-591-A PANEL BOARD, COMPLETE (JE)
A-4390-762-A PANEL BOARD, COMPLETE (TH)
**********************
JOY ENCODER BOARD
******************
VOL ENCODER BOARD
******************
* 4-932-810-01 CUSHION (FL)
* 4-971-014-01 HOLDER, FL TUBE
* 4-978-036-05 HOUSE, LAMP
< CAPACITOR >
C501 1-104-905-11 CAPACITOR 0.22uF 5.5V
C502 1-163-059-00 CERAMIC CHIP 0.01uF 10% 50V
C504 1-164-159-11 CERAMIC 0.1uF 50V
C505 1-164-159-11 CERAMIC 0.1uF 50V
C506 1-126-968-11 ELECT 100uF 20% 35V
C511 1-126-968-11 ELECT 100uF 20% 6.3V
C540 1-164-159-11 CERAMIC 0.1uF 50V
C541 1-126-233-11 ELECT 22uF 20% 50V
C542 1-164-159-11 CERAMIC 0.1uF 50V
C543 1-163-165-00 CERAMIC CHIP 22PF 5% 50V
C544 1-163-163-00 CERAMIC CHIP 18PF 5% 50V
C545 1-164-159-11 CERAMIC 0.1uF 50V
C5001 1-101-006-00 CERAMIC 0.047uF 50V
C5002 1-124-464-11 ELECT 0.22uF 20% 50V
C5003 1-101-004-00 CERAMIC 0.01uF 50V
C5004 1-130-473-00 MYLAR 0.0015uF 5% 50V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
MAIN
PANEL
JOY ENCODER
VOL ENCODER
