– 52 –
< TERMINAL >
TM1 1-537-238-21 TERMINAL BOARD (ANTENNA)
< VIBRATOR >
X21 1-567-713-11 VIBRATOR, CRYSTAL (4.5MHz) (TH)
X21 1-760-549-11 VIBRATOR, CRYSTAL (4.5MHz) (EXCEPT TH)
X41 1-760-220-11 FILTER, CERAMIC (10.7MHz)
X42 1-527-981-00 FILTER, CERAMIC (450kHz)
X43 1-577-075-11 OSCILLATOR, CERAMIC (19kHz)
************************************************************
* 1-658-764-11 TRANS (A) BOARD
***************
1-533-293-11 FUSE HOLDER
< CONNECTOR >
CN851 1-564-321-00 PIN, CONNECTOR 2P
< LEAD >
CP851 1-775-377-61 LEAD (WITH CONNECTOR) (US,CND)
< FUSE >
! F851 1-532-388-51 FUSE, TIME LAG (T2AL) (TH,AUS)
! F851 1-532-504-51 FUSE, TIME LAG (T4AL)
(EXCEPT US,CND,TH, AUS)
! F851 1-576-109-11 FUSE (5A/125V) (CND)
! F851 1-576-110-11 FUSE (6A/125V) (US)
! F852 1-532-388-51 FUSE, TIME LAG (T2AL)(E,EA,MY,SP,HK,AR,JE)
< RESISTOR >
! R851 1-202-725-00 SOLID 3.3M 10% 1/2W
(US,CND)
************************************************************
* 1-660-119-11 TRANSFORMER SECONDARY BOARD
******************************
1-533-293-11 FUSE HOLDER
< FUSE >
! F853 1-532-465-51 FUSE, TIME LAG (T3.15AL)
(EXCEPT US,CND)
! F853 1-576-107-11 FUSE (3.15A/250V) (US,CND)
! F854 1-532-465-51 FUSE, TIME LAG (T3.15AL)
(EXCEPT US,CND)
! F854 1-576-107-11 FUSE (3.15A/250V) (US,CND)
! F855 1-532-465-51 FUSE, TIME LAG (T3.15AL)
(EXCEPT US,CND)
! F855 1-532-781-41 FUSE, MICRO (SECONDARY) (US)
! F855 1-576-107-11 FUSE (3.15A/250V) (CND)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
! F856 1-532-465-51 FUSE, TIME LAG (T3.15AL)
(EXCEPT US,CND)
! F856 1-576-107-11 FUSE (3.15A/250V) (CND)
< RESISTOR >
! R898 1-213-036-61 FUSIBLE 1 5% 1W F
(US)
************************************************************
* 1-659-506-11 VOLTAGE SW BOARD (E,EA,MY,SP,HK,AR,JE)
*****************
1-533-293-11 FUSE HOLDER
< SWITCH >
! S851 1-572-367-11 SWITCH, VOLTAGE SELECTER)
(E,EA,MY,SP,HK,AR,JE)
************************************************************
MISCELLANEOUS
**************
8 1-533-293-11 FUSE HOLDER
! 21 1-574-805-11 CORD, POWER (EA,MY,SP,HK,AR)
! 21 1-575-653-11 CORD, POWER (E,JE)
! 21 1-575-975-11 CORD, POWER (US,CND)
! 21 1-690-608-11 CORD, POWER (AUS)
! 21 1-751-326-31 CORD, POWER (TH)
! 22 1-569-007-11 ADAPTER, CONVERSION 2P (E3,JE)
! 22 1-569-008-11 ADAPTER, CONVERSION 2P (EA,MY,SP)
! 22 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
! F851 1-532-388-51 FUSE, TIME LAG (T2AL) (TH,AUS)
! F851 1-532-504-51 FUSE, TIME LAG (T4AL)
(EXCEPT US,CND,TH,AUS)
! F851 1-576-109-11 FUSE (5A/125V) (CND)
! F851 1-576-110-11 FUSE (6A/125V) (US)
! F852 1-532-388-51 FUSE, TIME LAG (T2AL) (E,EA,MY,SP,HK,AR,JE)
! F853 1-532-465-51 FUSE, TIME LAG (T3.15AL)
(EXCEPT US,CND)
! F853 1-576-107-11 FUSE (3.15A/250V) (US,CND)
! F854 1-532-465-51 FUSE, TIME LAG (T3.15AL)
(EXCEPT US,CND)
! F854 1-576-107-11 FUSE (3.15A/250V) (US,CND)
! F855 1-532-465-51 FUSE, TIME LAG (T3.15AL)
(EXCEPT US,CND)
! F855 1-532-781-41 FUSE, MICRO (3.15A) (US)
! F855 1-576-107-11 FUSE (3.15A/250V) (CND)
! F856 1-532-465-51 FUSE, TIME LAG (T3.15AL)
(EXCEPT US,CND)
! F856 1-576-107-11 FUSE (3.15A/250V) (CND)
M601 1-698-651-11 FAN, DC (TH)
M601 1-698-792-11 FAN, DC (EXCEPT TH)
! S851 1-572-367-11 SWITCH, VOLTAGE SELECTER)
(E,EA,MY,SP,HK,AR,JE)
TRANS (A)
TCB
TRANSFORMER SECONDARY VOLTAGE SW
