KY-27EXR95
RM-Ylll
/
,SERVlCEMANUAL
*
US Model
Chassis No. SCC-DSOK-A
Canadian Model
Chassis No. SCC-Q61 E-A
ANU-2
CHASSIS
MODELS OF THE SAME SERIES
KV-27EXR95
Television system American TV standards
Channel coverage VHF: 2
-
13
UHF: 14
-
69
Picture tube
Antenna
Input
output
Cable TV: 1
-
125
MicroblackL’
Trinitronr
tube
27.inch
picture measured
diagonally
28-inch
picture tube measured
diagonally
75.ohm external anlenna terminal
for VHF/UHF
VIDEO
1
and 2 IN
S VIDEO IN
(4-pin
mini
DIN)
Y:
1
Vp-p,
75-ohms
unbalanced, sync negative
C: 0.286 Vp-p (Burst signal),
75ohms
Video (phono jacks): 1 Vp-p,
75-ohms unbalanced,
sync negative
Audio (phono jacks): 500
mVrms
(100% modulation)
Impedance: 47 kilohms
VIDEO 2 OUT
Video (phono jack):
75-ohms unbalanced,
sync negative
Audio (phono jacks):
Impedance: 10 kilohms
AUDIO OUT (VARIABLE)
(phono jacks)
More than 408
mVrms
at the
maximum volume setting
(variable)
Impedance: 5 kilohms
KV-27EXR90
SPECIFICATIONS
Speaker output
5Wx2
Power requirements 120 V AC, 60 Hz
Power consumption Maximum: 165 W
Standby: 1.5 W
Dimensions (h/w/d) 595
x
683
x
573.5 mm
(23%
x
27
x
22% inch)
Supplied accessories
Remote Commander RM-Ylll (1) with
2 size AA (R6) EVEREADY batteries
Terminal cover (1)
Recommended accessories
U/V mixer EAC-66
Connecting cable
VMC-8101820.S
YCi5V13OV
SPEAKER SIZE TWEETER 50mm X2
(2”)
WOOFER 85mm X2
(3 318”)
TOTAL 2 SPEAKER BOXES
INTERNAL
AUDIO POWER
FRONT 5 WATTS X 2
CONDITION
8 ohms, 10%
T.H.D
AUDIO FREQUENCY RESPONSE
TWEETER 2kHz
-2OkHz
WOOFER
50Hz
-2kHz
CONDITION
BASS/TREBLE ARE IN NORMAL CONDITION
Design and specifications are subject to change without
notice.
TRINITRONdOLOR
TV
s;ONYn
