TRINITRON
®
COLOR TELEVISION
SERVICE MANUAL DA-4 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION CHASSIS NO.
9-965-963-04
KV-27HS420 RM-Y197 US SCC-S66P-A
KV-27HS420 RM-Y197 CANADA SCC-S70N-A
KV-29DRC420 RM-Y197 LATIN NORTH SCC-S71L-A
KV-29DRC420 RM-Y197 LATIN SOUTH SCC-S71M-A
KV-30HS420 RM-Y197 US SCC-S66Q-A
KV-30HS420 RM-Y197 CANADA SCC-S70P-A
KV-30HS420 RM-Y197 HAWAII SCC-S69H-A
KV-32HS420 RM-Y197 US SCC-S66R-A
KV-32HS420 RM-Y197 CANADA SCC-S70Q-A
KV-34HS420 RM-Y197 US SCC-S66S-A
KV-34HS420 RM-Y197 CANADA SCC-S70R-A
KV-36HS420 RM-Y197 US SCC-S66T-A
KV-36HS420 RM-Y197 CANADA SCC-S70S-A
KV-36HS420 RM-Y197 HAWAII SCC-S69J-A
This manual is for units starting with the following S/N’s:
4,000,001 to 4,499,999
8,000,001 to 8,499,999
9,000,001 to 9,499,999
Self Diagnosis
Supported model
KV-30HS420
RM-Y197
