Sony VGN-S50B - Default Chapter; Table of Contents

— 3 —
Confidential
VGN-S50B/S70B/S90PS/S90S (J)
VGN-S150/S150F/S150FP/S150P/S170/S170B/S170F/S170P (AM)
VGN-S1HP/S1VP/S1XP (EU)
VGN-S16C/S16GP/S16LP/S16SP/S16TP/S17C/S18CP/S18GP/S18LP/S18SP/S18TP (AO)
TABLE OF CONTENTS
Section Title Page
CHAPTER 1. SPECIFICATIONS
1-1. Specifications .......................................................................................................................... 1-1
(to 1-4)
CHAPTER 2. BLOCK DIAGRAM ...................................................................................... 2-1
(to 2-1)
CHAPTER 3. FRAME HARNESS DIAGRAM ................................................................ 3-1
(to 3-1)
CHAPTER 4. EXPLODED VIEWS AND PARTS LIST
Palmrest
P-1 ........................................................................................................................................... 4-2
Main Board
M-1 ......................................................................................................................................... 4-4
Bottom
B-1 .......................................................................................................................................... 4-6
LCD
L-1. 13.3-inch WXGA (Brighter) ........................................................................................... 4-8
L-2. 13.3-inch WXGA .......................................................................................................... 4-10
Accessories
A-1 ........................................................................................................................................ 4-12
(to 4-12)
CHAPTER 5. OTHERS
5-1. The Barcode Label .................................................................................................................. 5-1
5-2. Replacing the CPU ................................................................................................................. 5-2
(to 5-2)
Section Title Page
History of the changes is shown as the "Revision
History" at the end of this data.
ᄌᦝጁᱧߪ㧘4GXKUKQP*KUVQT[ߣߒߡ㧘ᧄ࠺࡯࠲ᧃߦ⸥
タߒߡ޽ࠅ߹ߔޕ
