4-3
VGN-U71P/U750P/U8G/U8C (J/AM/AO)
Confidential
Ref.No. Part No. Description
MS-1. Main Section
MS-1
4 1-756-424-11 BATTERY, VANADIUM-LITHIUM
5 4-673-488-01 BLIND SHEET(BOTTOM)
*6 4-681-899-01 BRACKET (FAN)
*7 4-681-900-01 BRACKET HDD
8 4-681-954-01 BUTTON (H)
9 4-681-955-01 BUTTON (PW)
10 4-681-906-02 BUTTON (SE)
11 4-681-953-01 BUTTON (ST)
12 4-681-956-01 BUTTON (WL)
13 4-681-894-01 CABINET BOTTOM
15 4-681-896-02 & CARD DUMMY
16 4-681-895-01 COVER FAN
18 4-678-799-11 CUSHION (HDD)
19 4-683-263-01 CUSHION (SCALE)
21 X-4626-638-2 ESCUTCHEON SUB ASSY
22 1-478-683-11 FAN
30 4-681-951-02 LED LENS (MS)
31 4-681-957-01 LED LENS (WL)
32 4-681-958-01 LEVER BATTERY
33 4-681-902-01 & LID (MS)
34 4-681-901-01 & LID (SCALE)
35 4-681-961-01 BATTERY LOCK L
36 4-681-959-01 BATTERY LOCK R
39 4-681-903-01 OFF (W) STAND
43 4-642-711-01 SHEET (BATTERY), ADHESIVE
44 4-681-904-02 SHEET (BOTTOM) INSULATING
46 4-669-950-01 SHEET (HDD), INSULATING
47 2-050-542-01 SHEET (KAPTON) (SMALL)
48 4-682-871-01 SHEET (MEMORY)
*51 4-681-898-01 STRAP L BRACKET
*52 4-681-897-01 STRAP R BRACKET
53 4-658-789-02 TAPE (HARNESS)
54 4-673-367-02 THERMAL SHEET(CPU)
57 1-794-548-21 CONNECTOR, USB(A)
59 2-159-378-01 SHEET (AUDIO)
60 4-683-254-01 SHEET (MS LED)
61 4-681-960-01 SPRING (BATTERY)
62 - FILAMENT TAPE
67 2-187-373-01 SPACER (FAN)
B1 4-645-214-01 GRIP, M2 (M2X3)
B2 4-645-214-61 GRIP, M2 (M2X5)
B3 2-022-849-01 SCREW M2 EG (M2X1.8)
B4 2-022-855-01 <&> SCREW M2 EG (M2X2)
B5 2-022-862-02 & SCREW M2 EG (M2X8)
U71P
U750P
U8G
U8C
• This parts list contains two different types of parts.
The first type is the parts that are common to all models.
The other type is the parts that are different depending on each model.
• この部品表は、機種共通の部品と、機種によって使い分けが必要な部品に分かれています。
JAM AO
Ref.No. Part No. Description
[MA] 2 A-1068-872-A $ # 512MB MEMORY MODULE (S)
A-1068-873-A $ # 256MB MEMORY MODULE (S)
25 A-8118-089-A $ # HDD (20GB) (TO1.8) ASSY (S)
[MA] A-1099-381-A $ # HDD 30GB (TO1.8) ASSY (S)
[MA] 26 2-348-689-01 LABEL (ID)
[MA] 2-348-689-21 LABEL (ID)
2-348-689-31 LABEL (ID)
2-348-689-41 LABEL (ID)
[MA] 28 4-643-124-11 LABEL, SEAL
[MA] 37 A-1099-379-A $ # MBX-102 ASSY (D-P1100) (S)
A-1099-380-A $ # MBX-102 ASSY (D-C900) (S)
[MA] 55 1-805-595-11 # WIRELESS LAN MODULE PCWA-XM06
1-805-595-21 # WIRELESS LAN MODULE PCWA-XM06
1-805-595-31 # WIRELESS LAN MODULE PCWA-XM06
63 2-348-690-01 SHEET (HDD-MBX), EMI
64 2-348-691-01 SHEET (HDD-LCD), EMI
65 2-348-692-01 SHEET (ICH), EMI
66 2-583-738-01 CUSHION HDD (TOP)
1
1
1
1
1
1
1
1 1
[MA]
[MA]
