Help Guide
XLR Adaptor Kit
XLR-K3M
Selecting the audio input for recording audio to the channels on the camera
With the INPUT SELECT switch, select the audio input jack on the unit (INPUT1, INPUT2, or INPUT3) through which
audio is recorded to the channels on the attached camera.
Note
While the unit is attached to a camera, you cannot record the input audio from the built-in microphone or the microphone jack on
the camera.
When only the INPUT1 jack has an external device connected:
Set the switch to “IN1.” The input audio from the INPUT1 jack is recorded to both the CH1 and CH2 channels on the
attached camera.
When both the INPUT1 and INPUT2 jacks have an external device connected:
Set the switch to “IN1·IN2.” The input audio from the INPUT1 jack is recorded to the CH1 channel on the attached
camera while the input audio from the INPUT2 jack is recorded to the CH2 channel.
Hint
When using a stereo microphone with two XLR (3-pin, female type) plugs, connect the left-channel plug to the INPUT1 jack and
the right-channel plug to the INPUT2 jack, and then set the INPUT SELECT switch to “IN1·IN2.”
In addition, by setting the AUTO/MAN/LINK (INPUT2) switch to “LINK” comes in handy for stereo recording as you can
simultaneously adjust both the recording volume levels of the input audio from the INPUT1 and INPUT2 jacks.
When the INPUT3 jack has an external device connected:
Set the switch to “IN3.” Stereo audio is received through the INPUT3 jack and its left-channel audio is recorded to the
CH1 channel on the attached camera while the right-channel audio is recorded to the CH2 channel.
Related Topic
INPUT SELECT Audio input jack Channel to contain audio
IN1 INPUT1 CH1 and CH2
INPUT SELECT Audio input jack Channel to contain audio
IN1·IN2
INPUT1 CH1
INPUT2 CH2
INPUT SELECT Audio input jack Channel to contain audio
IN3
INPUT3 (L) CH1
INPUT3 (R) CH2
