Test and Calibration Repair Instruction Electrical/
1265-3289 Rev 2
Sony Mobile Communications AB – Company Internal
Go/NoGo Testing
1.2 Direct Line
The following equipment has to be used:
• RF Test Cable Flexible 1M
• RF Probe
• USIM Card, instrument specific
Connect the RF Probe as shown in the adjacent picture.
To get access to the RF connector on the PBA, refer to
1263-4086: ST25 Mechanical Working Instructions,
Chapter 3.1!
