Sony XR-55A80L Service Manual

Smart Core
Red LED blinking
count
Error Name Retry Permission Times
*1
Note
2x MAIN_POWER
STDWN_RTRY_LIMIT_MAINPOWR = 1
3x
DC_ALERT (5V) STDWN_RTRY_LIMIT = 2
AUD_ERR STDWN_RTRY_LIMIT = 2
4x
LD_ERR STDWN_RTRY_LIMIT = 2
BCM_ERR STDWN_RTRY_LIMIT = 2
5x P_ID_ERR STDWN_RTRY_LIMIT = 2
6x BACKLIGHT STDWN_RTRY_LIMIT = 2
7x TEMP_ERR STDWN_RTRY_LIMIT = 2
8x 4KBE_ERR STDWN_RTRY_LIMIT = 2
14
Number of off/on action during the
error shutdown is recorded to
STDWN_OFFON_CNT
*2
.
Number of off/on action for MAIN_POWER
shutdown is recorded to
STDWN_OFFON_CNT_MAIN_POWER
*2
.
*1) If STDWN_OFFON_CNT <= STDWN_RTRY_LIMIT, and STDWN_OFFON_CNT_MAIN_POWER <= STDWN_RTRY_LIMIT_MAINPOWR, you can turn the set on
by a remote/power key. At this time, if the error occurs again, the STDWN_OFFON_CNT is incremented by 1.
*2) When the main micro operates normally for STDWN_OFFON_CLR = 60 minutes, STDWN_OFFON_CNT and STDWN_OFFON_CNT_MAIN_POWER are cleared.
Retry Limitation by Remote/Power Key
SELF DIAGNOSIS FUNCTION
SYSSET
2023/11/2806:39:49(GMT+09:00)

Sony XR-55A80L Specifications

General

AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy saving mode	Yes
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	362 W
Screen shape	Flat
Response time	- ms
Display diagonal	55 \
Display brightness	- cd/m²
Display technology	OLED
Native aspect ratio	16:9
Contrast ratio (typical)	-
Display diagonal (metric)	139 cm
Supported graphics resolutions	3840 x 2160
Tuner type	Analog & digital
Supported TV bands	UHF, VHF
Analog signal format system	PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2
Music apps	Classic FM, Spotify, YouTube Music
Video apps	4oD, All 4, Amazon Prime Video, Apple TV, DAZN, Disney+, Freeview Play, Google TV, ITV Hub, My5, Rakuten TV, Vimeo, YouTube
Smart modes	Photo, Cinema, Custom, Game, Vivid, Graphics, Netflix Calibrated, Dolby Vision Bright, IMAX Enhanced, Dolby Vision Dark, Standard
Sports apps	BT Sport
Lifestyle apps	Facebook, Google Apps, Skype
Operating system version	Android 10
App distribution platform	Google Play
Operating system installed	Android
Sound modes	Cinema, Dialog, Dolby Audio, Music, Sports, Standard
Audio decoders	Dolby Atmos
RMS rated power	50 W
Number of speakers	5
PC in (D-Sub)	No
RF ports quantity	1
HDMI ports quantity	4
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP, HID, HOGP, SPP
Product color	Black
Panel mounting interface	300 x 300 mm
Picture processing technology	Sony XR HDR Remaster, Sony XR Smoothing, Sony XR Super Resolution, Sony XR Triluminos Pro
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
Package depth	842 mm
Package width	1342 mm
Package height	176 mm
Package weight	25000 g
Cables included	AC

Weight and Dimensions

Stand width	1164 mm
Depth (with stand)	327 mm
Height (with stand)	738 mm
Weight (with stand)	18800 g
Depth (without stand)	53 mm
Width (without stand)	1227 mm
Height (without stand)	712 mm
Weight (without stand)	17900 g
