– 45 –
Pin No. Pin Name I/O Function
117 TAPE MUTE O
Tape muting on/off control signal output to the CXA2509AQ (IC301) “H”: muting on
Active at ATA, FF/REW mode
118 AMP ON O
Standby on/off control signal output to the power amplifier (IC611)
“L”: standby mode, “H”: amp on
119 VSS
—
Ground terminal
120 POWON
O Main system power supply on/off control signal output to the BA3918 (IC671) “H”: power on
*1 Loading/tape operation motor control
STOP
LOADING/
FORWARD
EJECT/
REVERSE
BRAKE
LM-LOD (pin `⁄⁄‚)
“L” “H” “L” “H”
LM-EJ (pin `⁄‚·)
“L” “L” “H” “H”
Mode
Terminal
