Sony XR-C5120R User Manual

– 52 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D441 8-719-105-99 DIODE RD6.2M-B1
D481 8-719-105-99 DIODE RD6.2M-B1
D501 8-719-914-44 DIODE DAP202K
D551 8-719-105-99 DIODE RD6.2M-B1
D552 8-719-105-99 DIODE RD6.2M-B1
D553 8-719-105-99 DIODE RD6.2M-B1
D554 8-719-105-99 DIODE RD6.2M-B1
D555 8-719-056-93 DIODE UDZ-TE-17-18B
D556 8-719-105-99 DIODE RD6.2M-B1
D557 8-719-105-99 DIODE RD6.2M-B1
D558 8-719-105-99 DIODE RD6.2M-B1
D559 8-719-105-99 DIODE RD6.2M-B1
D561 8-719-105-99 DIODE RD6.2M-B1
D562 8-719-105-99 DIODE RD6.2M-B1
D571 8-719-404-50 DIODE MA111-TX (C5120R)
D601 8-719-049-38 DIODE 1N5404TU
D602 8-719-056-93 DIODE UDZ-TE-17-18B
D603 8-719-056-93 DIODE UDZ-TE-17-18B
D604 8-719-105-99 DIODE RD6.2M-B1
D605 8-719-056-93 DIODE UDZ-TE-17-18B (C5120R)
D611 8-719-053-18 DIODE 1SR154-400TE-25
D612 8-719-053-18 DIODE 1SR154-400TE-25
D613 8-719-053-18 DIODE 1SR154-400TE-25
D614 8-719-053-18 DIODE 1SR154-400TE-25
D615 8-719-053-18 DIODE 1SR154-400TE-25
D616 8-719-053-18 DIODE 1SR154-400TE-25
D617 8-719-053-18 DIODE 1SR154-400TE-25
D618 8-719-053-18 DIODE 1SR154-400TE-25
D621 8-719-422-12 DIODE MA8039
D622 8-719-404-50 DIODE MA111-TX
D623 8-719-977-22 DIODE DTZ9.1
D624 8-719-404-50 DIODE MA111-TX
D625 8-719-914-44 DIODE DAP202K
D631 8-719-158-49 DIODE RD12SB2
D651 8-719-911-19 DIODE 1SS119
D653 8-719-404-50 DIODE MA111-TX
D661 8-719-404-50 DIODE MA111-TX
D662 8-719-056-85 DIODE UDZ-TE-17-8.2B
D671 8-719-970-02 DIODE 1SR139-400
D672 8-719-970-02 DIODE 1SR139-400
D673 8-719-970-02 DIODE 1SR139-400
D674 8-719-970-02 DIODE 1SR139-400
D701 8-719-056-93 DIODE UDZ-TE-17-18B
D702 8-719-017-62 DIODE MA8068-L-TX
D703 8-719-105-99 DIODE RD6.2M-B1
D704 8-719-056-93 DIODE UDZ-TE-17-18B
D705 8-719-056-93 DIODE UDZ-TE-17-18B
D706 8-719-072-70 DIODE MA2ZD14001S0
< COIL >
FB501 1-414-233-22 INDUCTOR CHIP 0uH
< IC >
IC1 8-759-573-79 IC TB2118F(EL)
IC51 8-759-492-59 IC SAA6588T-118
IC90 8-759-909-71 IC BA4558F
IC301 8-752-079-78 IC CXA2509AQ-T4
IC361 8-759-823-87 IC LB1638M
IC401 8-759-572-10 IC TDA7462D
IC501 8-759-585-83 IC MB90574PFV-G-196-BND
IC611 8-759-490-74 IC TDA7384
IC652 8-759-574-61 IC XC61AN4302MR
IC671 8-759-347-50 IC BA3918-V3
IC701 8-759-449-89 IC BA8270F-E2
< JACK >
J1 1-764-808-21 JACK (FM/AM ANTENNA)
J501 1-566-822-41 JACK (REMOTE IN)
< SHORT >
JC1 1-216-295-00 SHORT 0
JC301 1-216-295-91 SHORT 0 (C5120R)
JC503 1-216-295-00 SHORT 0
< COIL >
L51 1-410-509-11 INDUCTOR 10uH
L601 1-411-669-21 COIL, CHOKE
< TRANSISTOR >
Q51 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q61 8-729-921-25 TRANSISTOR FMC2
Q71 8-729-015-11 TRANSISTOR 2SD1802FAST-TL
Q81 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q82 8-729-921-25 TRANSISTOR FMC2
Q90 8-729-900-53 TRANSISTOR DTC114EK
Q121 8-729-920-21 TRANSISTOR DTC314TKH04
Q151 8-729-920-21 TRANSISTOR DTC314TKH04
Q171 8-729-920-21 TRANSISTOR DTC314TKH04
Q181 8-729-920-21 TRANSISTOR DTC314TKH04
Q251 8-729-920-21 TRANSISTOR DTC314TKH04
Q271 8-729-920-21 TRANSISTOR DTC314TKH04
Q281 8-729-920-21 TRANSISTOR DTC314TKH04
Q361 8-729-015-11 TRANSISTOR 2SD1802FAST-TL
Q362 8-729-921-25 TRANSISTOR FMC2
Q364 8-729-106-60 TRANSISTOR 2SB1115A
Q365 8-729-900-53 TRANSISTOR DTC114EK
Q571 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (C5120R)
Q621 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q622 8-729-021-94 FET 2SK1657-T1B
Q631 8-729-423-99 TRANSISTOR 2SD2137-OP
Q633 8-729-921-25 TRANSISTOR FMC2
Q651 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q652 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q661 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q701 8-729-900-53 TRANSISTOR DTC114EK
< RESISTOR >
R1 1-216-049-11 RES,CHIP 1K 5% 1/10W
R2 1-216-029-00 METAL CHIP 150 5% 1/10W
R3 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R6 1-216-073-00 METAL CHIP 10K 5% 1/10W
R7 1-216-073-00 METAL CHIP 10K 5% 1/10W
R8 1-216-073-00 METAL CHIP 10K 5% 1/10W
R11 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
