– 54 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R554 1-216-025-00 RES,CHIP 100 5% 1/10W
R555 1-216-097-00 RES,CHIP 100K 5% 1/10W
R556 1-216-097-00 RES,CHIP 100K 5% 1/10W
R558 1-216-025-00 RES,CHIP 100 5% 1/10W
R559 1-216-025-00 RES,CHIP 100 5% 1/10W
R560 1-216-025-00 RES,CHIP 100 5% 1/10W
R561 1-216-025-00 RES,CHIP 100 5% 1/10W
R611 1-216-049-11 RES,CHIP 1K 5% 1/10W
R612 1-216-049-11 RES,CHIP 1K 5% 1/10W
R621 1-216-017-00 RES,CHIP 47 5% 1/10W
R622 1-216-295-00 SHORT 0
R623 1-216-073-00 METAL CHIP 10K 5% 1/10W
R624 1-216-049-11 RES,CHIP 1K 5% 1/10W
R631 1-249-383-11 CARBON 1.5 5% 1/6W
R632 1-249-383-11 CARBON 1.5 5% 1/6W
R633 1-249-383-11 CARBON 1.5 5% 1/6W
R634 1-249-383-11 CARBON 1.5 5% 1/6W
R636 1-216-037-00 METAL CHIP 330 5% 1/10W
R641 1-216-097-00 RES,CHIP 100K 5% 1/10W
R642 1-216-113-00 METAL CHIP 470K 5% 1/10W
R651 1-216-113-00 METAL CHIP 470K 5% 1/10W
R652 1-216-097-00 RES,CHIP 100K 5% 1/10W
R653 1-208-806-11 RES,CHIP 10K 0.5% 1/10W
R654 1-216-073-00 METAL CHIP 10K 5% 1/10W
R655 1-216-025-00 RES,CHIP 100 5% 1/10W
R656 1-216-025-00 RES,CHIP 100 5% 1/10W
R661 1-249-421-11 CARBON 2.2K 5% 1/4W
R662 1-216-081-00 METAL CHIP 22K 5% 1/10W
R663 1-216-089-00 RES,CHIP 47K 5% 1/10W
R664 1-216-089-00 RES,CHIP 47K 5% 1/10W
R683 1-216-089-00 RES,CHIP 47K 5% 1/10W
R701 1-216-017-00 RES,CHIP 47 5% 1/10W
R702 1-216-073-00 METAL CHIP 10K 5% 1/10W
R703 1-216-025-00 RES,CHIP 100 5% 1/10W
R704 1-216-025-00 RES,CHIP 100 5% 1/10W
< CONPOSITION CIRCUIT BLOCK >
RB601 1-233-413-11 RES, CHIP NETWORK 2.2K (3216)
RB602 1-233-810-21 RES, NETWORK 100K (3216)
< VARIABLE RESISTOR >
RV1 1-223-836-11 RES, ADJ, CARBON 220K
< SWITCH >
S501 1-571-478-11 SWITCH, SLIDE (POWER SELECT)
S503 1-692-431-21 SWITCH, TACTILE (RESET)
< THERMISTOR >
TH701 1-801-792-21 THERMISTOR, POSITIVE
< TUNER >
TU1 1-693-440-21 TUNER UNIT FAE342-E01 (FM/AM)
< VIBRATOR >
X1 1-781-246-11 VIBRATOR, CRYSTAL (10.25MHz)
X51 1-579-242-41 VIBRATOR, CRYSTAL (4.332MHz)
X501 1-767-833-21 VIBRATOR, CERAMIC (3.68MHz)
X502 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
************************************************************
MISCELLANEOUS
**************
13 1-782-093-11 CORD (WITH CONNECTOR) (ISO-S)
(SPEAKER)
14 1-777-989-21 CORD (WITH CONNECTOR) (AMP REM)
(C5110R)
14 1-777-989-41 CORD (WITH CONNECTOR) (AMP REM, ATT)
(C5120R)
15 1-782-092-11 CORD (WITH CONNECTOR) (ISO-P) (POWER)
F801 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) (10A)
HP901 1-500-196-21 HEAD, MAGNETIC (PLAYBACK)
M901 A-3291-665-A MOTOR ASSY, MAIN (CAPSTAN/REEL)
************************************************************
**************
HARDWARE LIST
**************
#1 7-621-772-10 SCREW +B 2X4
#2 7-685-793-09 SCREW +PTT 2.6X8 (S)
#3 7-685-792-09 SCREW +PTT 2.6X6 (S)
#4 7-685-795-09 SCREW +PTT 2.6X12 (S)
#5 7-685-106-19 SCREW +P 2X10 TYPE2 NON-SLIT
#6 7-624-104-04 STOP RING 2.0, TYPE-E
#7 7-627-553-17 PRECISION SCREW +P 2X2 TYPE 3
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
3-865-674-11 MANUAL, INSTRUCTION (ENGLISH, SPANISH,
SWEDISH, PORTUGUESE) (AEP, UK)
3-865-674-21 MANUAL, INSTRUCTION (FRENCH, GERMAN,
DUTCH, ITALIAN) (AEP)
3-865-674-31 MANUAL, INSTRUCTION (GERMAN, RUSSIAN)
(German)
3-865-674-41 MANUAL, INSTRUCTION (ENGLISH, GREEK,
CZECH, POLISH, TURKISH) (South European)
3-865-675-11 MANUAL, INSTRUCTION, INSTALL (ENGLISH,
SPANISH, SWEDISH, PORTUGUESE) (AEP, UK)
3-865-675-21 MANUAL, INSTRUCTION, INSTALL (FRENCH,
GERMAN, DUTCH, ITALIAN, RUSSIAN)
(AEP, German)
3-865-675-31 MANUAL, INSTRUCTION, INSTALL (ENGLISH,
CZECH, POLISH, TURKISH, GREEK)
(South European)
X-3373-412-1 CASE (PANEL) ASSY (for FRONT PANEL)
************************************************************
MAIN
