a) Transition with a background selected for a next transition
b) Transition with a key selected for a next tran
sition or an independent key
transition
DME wipe pattern modifiers
You can add various modifiers to a DME wipe pattern,
such as setting the DME wipe direction and pattern
position.
Pattern limit
You can specify the transition execution limit of a DME
wipe.
For details, see “Pattern Limit” (page 105).
In an independent key transition, a pa
ttern limit cannot be
used.
DME wipe restrictions
Relationship with processed keys
• In DME wipes and processed keys, only enabled DME
channe
ls on the switcher bank can be used.
When using a DME in a processed key, an available
DME cha
nnel is automatically assigned for DME
wipes. If all DME channels are in use, then a DME wipe
cannot be used.
For details about setting DME channels, see “Setting a
DME channel to use in a switcher bank” (page 387).
• DME wipes and resizer DME wipes cannot be used on
key
s that use a DME in a processed key.
Relationship with the image effect function
It is not possible to use background DME wipes when the
image e
ffect function is set.
Relationship with resizers
• DME wipes and resizer DME wipes cannot be used on
keys with a
resizer enabled.
• When a dual resizer effect is set on either of the two
keys,
DME wipes and resizer DME wipes cannot be
used on the other key.
Number of DME channels that can be used
s
imultaneously
DMEs can be used in up to two locations simultaneously
on
a single switcher bank (processed key with DME
wipe).
The number of DME channels that
can be used on a key
depends on the DME wipe pattern execution mode, as
given below.
When not using a DME wipe:
One DME channel each on two ke
ys, or one to four
DME channels on a single key can be used.
When using a 1-channel mode DME wipe:
One DME channel on a single key only can be used.
When using a 2-channel mode or 3-channel mode DME
wi
pe:
DMEs cannot be used on keys.
• In multi program 2 mode, DMEs can be used in up to
t
wo locations (main and sub).
• When M/E split is enabled, one DME channel can be
u
sed on each of the two sub blocks.
Mosaic 1ch 1701 a ×
Defocus 1ch 1702 a ×
Crop Slide 2ch 2661, 2662 a ×
Brick 2ch 2801 to
28
04, 2811
to 2814
a ×
3ch 3601 a ×
Resizer
Slide
1ch 7001 to
70
08
× a
Resizer
Squ
eeze
1ch 7021 to
7031
× a
Resizer
Frame I/O
1ch 7201 to
72
08, 7221
to 7224
× a
Note
Pattern
group
Execution
mode
Pattern
number
Background
a)
Keys
b)
Notes
