297
A key snapshot cannot be registered using the numeric
keypad control block.
1
Recall an effect timeline register/snapshot register to
register in a shotbox.
To register an effect timeline register
Press the [EFF] button to switc
h to effect timeline
operation mode and select the target register to
register for each region.
For details about the metho
d of operation, see
“Recalling an Effect Timeline” (page 258).
To register a snapshot register
Press the [SNAPSHOT] button t
o switch to snapshot
operation mode and select the target register to
register for each region.
For details about the metho
d of operation, see
“Recalling a Snapshot” (page 283).
2
Press the [SHOTBOX] button.
The [SHOTBOX] button and [RCALL] button turn
o
n amber, and the numeric keypad control block
switches to shotbox operation mode.
3
Press the [STORE] button.
The [RCALL] button
turns off and the [STORE]
button turns on amber.
The [EFF] button (for an effect
timeline) or the
[SNAPSHOT] button (for a snapshot) turns on green.
If the [EFF] button/[SNAPSHOT
] button does not
turn on, press the [EFF] button/[SNAPSHOT] button,
turning it on green.
4
Select a region for the effect timeline/snapshot to
register in the shotbox using the region selection
buttons.
Press the region selection button, turning it on, for the
target region to
register.
For details about selecting a region, see “Selecting a
region” (page 257).
5
Enter a shotbox register number in the numeric
keypad area.
6
Press the [ENTER] button.
The [STORE] button turns off
and the [RCALL]
button turns on amber.
Editing a shotbox
You can change an effect timeline/snapshot register and
the region to register in a shotbox.
1
Press the [SHOTBOX] button.
The [SHOTBOX] button and [RCALL] button turn
on amber, and
the numeric keypad control block
switches to shotbox operation mode.
2
Recall the target shotbox register to edit.
Enter a register number in the numeric keypad area
an
d press the [ENTER] button.
3
Change the effect timeline register/snapshot register
registration.
To change an effect time
line register registration
Press the [EFF] button to swit
ch to effect timeline
operation mode and select the target register to
register for each region.
For details about the method of operation, see
“Recalling an Effect Timeline” (page 258).
To change a snapshot register registration
Press the [SNAPSHOT] button to
switch to snapshot
operation mode and select the target register to
register for each region.
For details about the method of operation, see
“Recalling a Snapshot” (page 283).
4
Press the [STORE] button.
The [RCALL] button turns off
and the [STORE]
button turns on amber.
The [EFF] button (for an effect
timeline) or the
[SNAPSHOT] button (for a snapshot) turns on green.
To delete the region for an effect tim
eline/
snapshot registered in a shotbox
Press the region selection but
ton, turning it off, for the
target region to delete.
To check the region for an
effect timeline
registered in a shotbox
While the [EFF] button is lit, press and hold the
[STORE] but
ton. While the [STORE] button is
pressed, the region selection button for the region in
which the effect timeline is registered is lit amber.
To check the region for a snapshot registere
d in a
shotbox
While the [SNAPSHOT] button is lit, press and hold
the
[STORE] button. While the [STORE] button is
pressed, the region selection button for the region in
which the snapshot is registered is lit amber.
Note
Note
