Align the bottom of nozzle with the air outlet mesh and gently snap into it. If you hear a

"click", then it is well installed.

Nozzle Installation and Dismantling

04

Installation Method

Pull the nozzle down from the appliance's air outlet, and remove the nozzle.

Dismantling Method

Spreading

nozzle

Concen-

trator
