12/14
Suitable model:X5.5
Specifications
Output power
Product dimension(mm)
The manufacturer reserves the rights to make changes in specification without prior notice.
The final specification is subject to the user's manual.
Connection
Balance input XLR-F, Balance output XLR-M
Input
NL4 SPEAKON
Output
Function
Other Specifications
Cooling
Air flow from rear to front
Input impedance(bal/unbal)
20kΩ/10kΩ
Dimensions/Weight
.The power is tested under EIA standard
Remark：
X Series Power Amplifier
Frequency response
20Hz-20KHz(+0/-0.5dB)
Front panel Front panel indicator: Working indicator Signal/Clip/Protection/Power on/ volume control knob
Protection
Soft start , DC short circuit over load clip limit over heat, VHF , , , ,
S/N rate
≥80dB ≥80dB≥80dB
8Ω stereo
4Ω stereo
Model
2Ω stereo
4Ω bridge
8Ω bridge
550Wx2
1350Wx2
800Wx2
950Wx2 2030Wx2
1280Wx2
X5.5
X13
X8.0
1900W
4050W2550W
2800W 5400W3400W
1300Wx2
2700Wx2
1700Wx2
THD+N
≤0.2% ≤0.05% ≤0.05%
Input sensitivity
0.775/1.0V/1.4V
Voltage gain (8 ohm）
38.4dB 40.5dB 42.5dB
Output circuitry
Class AB Class 3H Class 3H
Packaging Dimension(mm)
620x585x170 620x585x210620x585x210
G.W.
27.1kg 33.1kg 38kg
Product Dimension(mm)
483x486x89 483x486x133 483x486x133
Power Supply
2.5² cable 2.5² cable13A power cord
Suitable model:X8.0/X13
