Soundoff Signal PSRNHHC Series User Manual

1.800.338.7337 / www.soundoffsignal.com
PSRNHHC1 2.19.14
4
Level Switch Mapping:
1. Press Auxiliary Buttons #4 and #5 until RR LED Flashes
2. Press Level 1,2, or 3 switch to select level to be programmed
3. Press Auxiliary Buttons #1-#6 as required. LED ON =
function will turn ON when Level
is active
4. Press siren button for desired tone to be generated for level
Alley Left = Tone 1
Alley right = Tone 2
Alley Left and Right = Tone 3
Setting Backlight/Indicator LED Intensity:
1. Press and Hold Radio Rebroadcast (RR) Button.
2. Then press Aux Buttons 1-6 to select intensity.
1 = Low Intensity
6 = High Intensity
Default - All level #’s produce no tone
AUX
BUTTON #4
AUX
BUTTON #5
AUX
BUTTON #6
PRIMARY
SPKR 1 TONE
SECONDARY
SPKR 2 TONE
OFF OFF OFF Disabled Disabled
OFF OFF ON WAIL 1 WAIL 2
OFF ON OFF Yelp 1 Yelp 1
OFF ON ON ALERT A YELP 1
ON OFF OFF Piercer 1 Yelp 1
ON OFF ON HiLo Super HiLo Tone
ON ON OFF Super HiLo Tone Wail 1
ON ON ON Cycle Tone
(Wail 1, Yelp 1, Alert A, Piercer)
Cycle Tone
(Yelp 1, Alert A, Piercer, Yelp 1)
Tone #2
AUX
BUTTON #4
AUX
BUTTON #5
AUX
BUTTON #6
PRIMARY
SPKR 1 TONE
SECONDARY
SPKR 2 TONE
OFF OFF OFF Disabled Disabled
OFF OFF ON WAIL 1 WAIL 2
OFF ON OFF Yelp 1 Yelp 2
OFF ON ON ALERT A YELP 1
ON OFF OFF Piercer 1 Wail1
ON OFF ON HiLo Wail 1
ON ON OFF Super HiLo Tone Piercer 1
ON ON ON Cycle Tone
(Wail 1, Yelp 1, Alert A, Piercer)
Cycle Tone
(Yelp 1, Alert A, Piercer, Yelp 1)
Tone #3
BUTTON
#4
BUTTON
#5
BUTTON
#6
SPKR 1
TONE
SPKR 2
TONE
OFF OFF OFF HORN 1 HORN 1
OFF OFF ON HORN 2 HORN 2
OFF ON OFF HORN 3 HORN 3
OFF ON ON HORN 4 HORN 4
ON OFF OFF HORN 1 HORN 2
ON OFF ON HORN 2 HORN 3
ON ON OFF HORN 3 HORN 4
ON ON ON HORN 4 HORN 2
HORN BUTTON
BUTTON
#4
BUTTON
#5
BUTTON
#6
SPKR 1 TONE SPKR 2 TONE
OFF OFF OFF WAIL 1 (W/FREQ. DECREASE) WAIL 1 (W/FREQ. DECREASE)
OFF OFF ON WAIL 1 (IMMEDIATE OFF) WAIL 1 (IMMEDIATE OFF)
OFF ON OFF YELP 1 YELP 1
OFF ON ON PIERCER PIERCER
ON OFF OFF ALERT A ALERT A
ON OFF ON HiLo HiLo
ON ON OFF SUPER HiLo SUPER HiLo
ON ON ON WAIL 1 (IMMEDIATE OFF) WAIL 1 (IMMEDIATE OFF)
MANUAL BUTTON (SOLO PLAY ONLY)
