Source 1 S1-TBSU305-S User Manual

5
Get To Know Your Thermostat
13 Fan On icon —Indicates constant, continuous fan operation.
When Fan On is not lit - indicates the fan will only operate
when necessary to heat or to cool.
14 Lo icon—Indicates the lowest recorded outdoor temperature
for the day.*
15 AuxHeat icon—Indicates 2nd stage electric strip heat is being
used when the thermostat is programmed for Heat Pump
operation. Only the Aux icon will appear during Cool to
Dehumidify to indicate Reheat operation.
16 Hi icon—Indicates the highest recorded outdoor temperature
for the day.*
* Hi and Lo Temperatures for the day, reset at midnight.
HI
Lo
Program
Unoccupied123
ONOFF
Outdoor
Fan On
A UX H EAT
Override
Setup Step
2nd3rd
Stage
Am
Pm
18:88
188
188
88
188
16
15
14
13
Display Features

Source 1 S1-TBSU305-S Specifications

General

Brand	Source 1
Model	S1-TBSU305-S
Category	Thermostat
Language	English
