RELEASED TO PRODUCTION
1~
M
TB-11
R1
T1
L1
GB-1
0VDC
TB-4
115VAC/1PH/0.25HP
TB-12
TB-12
TB-11
TB-11
CUSTOMER
POWER
CORD
L1
GB-1
+24VDC
TB-1
N
L
(+)
(-)
24 VDC
POWER SUPPLY
G
TB-12
L2
ROCKER SWITCH
TB-12
10 AMP
4B
3B
1A
A
B
TORQUE SPECIFICATIONS
ITEM
MIN-MAX
FUSE BLOCK
0.8 Nm - 1.6 Nm
TERMINAL BLOCK
0.4 Nm - 0.6 Nm
GROUND BLOCK
0.4 Nm - 0.6 Nm
PLC
0.22 - 0.25 Nm
POWER SUPPLY
0.67 Nm MAX
TERMINAL BLOCK
FUNCTION
1-3 JUMPED
+24VDC
4-7 JUMPED
0VDC
8
PLC/NO0
9
PLC/NO2
10
PLC/NO4
11
L1
12
L2
WIRING TABLE
AWG
COLOR
SERVICE
FIELD/INTERNAL
14-16
BLACK
110VAC/L1
INTERNAL
14-16
WHITE
110VAC/L2
INTERNAL
16-18
BROWN
+24VDC
INTERNAL
16-18
BLUE
0V
INTERNAL
16-22
GRAY/RED
SIGNAL
INTERNAL
14-16
ANY
110VAC
FIELD
SCALE:
DATE:
APPROVED:
REVISION:
ES-FPS-00900-RS
01
PJS
1:1
DRAWN:
1 OF 2
B
NUMBER:
SIZE:
SHEET:
DATE:
06/18/19
PROJECT NAME:
ELECTRICAL SCHEMATICS
WEIGHT:
MATERIAL:
FINISH:
ELECTRICAL SCHEMATIC, RELIABLE
INTEGRATION
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF SOUTH-TEK SYSTEMS. ANY REPRODUCTION IN
PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION
OF SOUTH-TEK SYSTEMS IS PROHIBITED.
SDA
06/28/19
D
C
B
A
1
8
7
6
5
4
3
2
D
C
B
A
8
7
6
5
4
3
2
1
DRAWN
APPR.
DATE
DESCRIPTION
CHANGED LEAD LENGTHS OF CUSTOMER WIRE AND REMOVED
POWER AND ALARM PLUGS AND CAPS
CHANGED LEAD LENGTHS PER CUSTOMER CHANGE. RELEASE TO
PRODUCTION
NEW PLC, NEW DRAWING FORMAT
01 10404
-
-
RD-091
C0
RD-091
-
SHEET
TASK#
REV
00
REVISIONS: ONLY THE LATEST 3 REVISIONS WILL BE SHOWN. OLDER REVISIONS CONSOLIDATED AND FILED.
03/20/19
NTA
KLM
MRT
PJS
06/18/19
PJS PJS
MRT
ANGLES
1/8
1/16
.005
.03
.2
1
.5
X/X>10'
X/X<10'
.XXX
.XX
.XX.
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES
