Introduction
The Southwire T200K Wire Tracer Kit can be used to trace
Phone, Data, Coax and General Purpose wiring.
The kit includes a transmitter, receiver, and adapters for
connection to multiple types of cables. All the components
are conveniently stored in a carrying case with belt clip.
With proper use, this tester will provide many years of
reliable service.
3. HANDLE THE TESTER WITH CARE.
Dropping it can damage the electronic parts or the case.
4. KEEP THE TESTER CLEAN. Wipe the case occasionally with
a damp cloth. DO NOT use chemicals, cleaning solvents, or
detergents.
5. USE ONLY FRESH BATTERIES OF THE RECOMMENDED
SIZE AND TYPE. Remove old or weak batteries so they do
not leak and damage the unit.
6. IF THE TESTER IS TO BE STORED FOR A LONG PERIOD
OF TIME, the batteries should be removed to prevent
damage to the unit.
Maintenance cont.
1 2
࠮9LHK\UKLYZ[HUKHUKMVSSV^:HML[`9\SLZHUK6WLYH[PUN
Instructions in this manual before using this tester.
࠮,SLJ[YPJZOVJROHaHYK+VUV[JVUULJ[[LZ[LY[VSP]LJPYJ\P[Z
5L]LY[YHJLLULYNPaLK^PYPUN
࠮+VUV[\ZL[OL[LZ[LYPM[OL[LZ[LYVY[LZ[SLHKZHWWLHYKHTHNLK
࠮+VUV[TVKPM`VY[Y`[VYLWHPY[OL[LZ[LY
No serviceable parts are inside.
࠮+VUV[\ZL[OL[LZ[LYPUH^L[VYKHTWLU]PYVUTLU[VYK\YPUN
electrical storms.
࠮+VUV[\ZL[OL[LZ[LYULHYL_WSVZP]LNHZLZK\Z[VY]HWVY
࠮-VYPUKVVY\ZLVUS`
WARNINGS
.LULYHS:WLJPÄJH[PVUZ
Tone Signal Frequency
Tone Output Power
Tone Auto-Off
Battery (Transmitter and Receiver)
Operating Temperature
Storage Temperature
Case dimensions
Tone dimensions
Probe dimensions
Weight
2.72 kHz nominal
+24 dbm into 600 ohms
30min
Two “AAA” 1.5V Batteries in each unit
4°F to 140°F (-20° to 60°C)
-40°F to 158°F (-40° to 70°C)
7.06 in. x 3.19 in. x 2.04 in.
(17.9 cm x 8.1 cm x 5.2 cm)
5.17 in. x 0.94 in. x 1.32 in.
(13.2 cm x 2.4 cm x 3.4 cm)
6.18 in. x 0.94 in. x 1.32 in.
(15.7 cm x 2.4 cm x 3.4 cm)
0.7lb (322g)
This tester is designed to provide years of dependable service,
if the following care instructions are performed:
1. KEEP THE TESTER DRY. If it gets wet, wipe it off.
2. USE AND STORE THE TESTER IN NORMAL
TEMPERATURES. Temperature extremes can shorten the life
of the electronic parts and distort or melt plastic parts.
Maintenance
