Sovereign M4E1232C - Assembling Handles; Assembling Grass Collection Box

16
Assemble the mower
• Insert the lower handle bar into the supports on
the deck (Fig. 2).
• Fix the lower handle bar using the enclosed screws
(Fig. 3).
• Fix the upper handle bar
3
using the enclosed bolts
and the wing nuts on the lower handle bar (Fig. 4).
There are two possible positions. Select the position
appropriate for the height of the user.
• Secure the cable against the handle frame with the
supplied cable clip supplied cable clip . Ensure the
cable must be clipped into the cable clip (Fig. 5).
13
5
10
5
11
4
19
5
18
18
Assembling Handles
Assembling the Grass Collection Box
WARNING! Wear protective gloves when mounting the
grass collection box in order to avoid injury.
8
9
6
6
8
• Fit the two halves of the grass collection box together.
The two halves are identical. Ensure that all plastic lugs
engage correctly (Fig. 6).
• Connect the grass collection box handle in one of the
two pieces of the grass collection box . The arrow
markings on the grass collection box handle and at
the top of the grass collection box show the alignment
of the grass collection box handle (Fig. 7).
7
6
We recommend always using the grass collection box
when working with the lawn mower, otherwise the
mowing result may be signicantly impaired.
