SP Shocker CVO - PARTS GUIDE: MANIFOLDS AND VALVES; Valve Manifold and Bolt Control Manifold Parts

24
SHOCKER CVO
WWW.SHOCKERPAINTBALL.COM
25
PLEASE READ CAREFULLY PLEASE READ CAREFULLY
VALVE MANIFOLD BOLT CONTROL MANIFOLD
008 3MM x 1MM
003
USE ORING TOOL (FXT030) TO SLIDE OB7M04 ONTO XTC122
012
0B7008
0U7003 SHM118
SHM116
0U7003
0B7M04
(3 X 1MM)
OB7012
SHM115
XTC122
SOS017
(RED LOCTITE 277)
SPR039
CLP010
SOS017
CLP010
OB7008 - AS008 buna 70 durometer
OB7M04 - 3mm x 1mm buna 70 durometer
OU7003 - AS003 urethane 70 durometer
OB7013 - AS013 buna 70 durometer
SOS017 - #4-40 x .125" black oxide set screw
SHM 2.0 VALVE ASM GUIDE
GOG PAINTBALL S.A.
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF
GOG PAINTBALL S.A. ANY REPRODUCTION IN PART OR WHOLE WITHOUT THE
WRITTEN PERMISSION OF GOG PAINTBALL S.A. IS PROHIBITED.
SHM VALVE ASM
SHM217
MAG005
OB7M22
(3.5 x 1MM)
OB7M22
(3.5 x 1MM)
SSB001
2.0 QEV ASM
PARTS GUIDE
PARTS GUIDE
