Spa Dynamix Vitala - Page 7

Getting to Know Your Chair Getting to Know Your Chair
1. Right Armrest Assembly
2. Remote Control
3. Right Side Fender
4. Electric Magnetic Valve
5. Leg Rest & Footrest
6. Air Pump Case
7. Seat Frame
8. Electric Actuator
9. Left Side Fender
10. Left Armrest Assembly
11. Seat Cushion
12. Massage Machine
13. Pillow
14. Back Cushion
15. Plastic Front Cover
16. Back Frame Assembly
17. Back Cover Assembly
18. Power Case Assembly
5
1
2
3
4
6 7 8 9
10
11
12
1413 15 16 17
18
109
