Stick Balsa
18 3/32"x1/4"x36" Capstrips 2 3/32"x3/4"x30" Bottom Aileron
Sheeting
1 1/8"x1/8"x24" Top Main Spar
Spacers
8 1/8"x1/4"x36" Aileron Spars,
Fill-Strips, Fabric Attach
Strips
7
1/8"x3/8"x36" Top Stringers, Cable
Exit Guides, Fill-Strips
3 1/8"x3/4"x36" Leading Edges 2 3/16"x1/4"x18" Fill-Strips 3 3/16"x3/8"x36" Tail Surface
Diagonal Ribs
18
1/4"x1/4"x36" Forward Spars, Main
Frames, Cross-Braces, Stringers
6 1/4"x1/2"x36" Rear Spars 3 1/4"x7/8"x36" Leading Edge
Caps
3 3/8"x3/8"x36" Tail Surface
Ribs
5 3/8"x3/4"x36" Tail Surface Frames 1 3/8" Triangle x2-1/2" Fin L.E.
Brace
1 3/4" Triangle x36" PW Brace,
Hold-down Block Brace, L.G.
Block Brace
1 I" Triangle x8" Firewall Brace
1 1/2"x 1-1/2"x8" Special Shaped
T.E. Fill-In Block
Hardwood
1 3/8"xI"x1-
Horn Mount
2 1/2"x19/32"x4" BASSWOOD Rear
L.G. Blocks, Grooved
2 1/2"xI"x4" BASSWOOD Front
L.G. Blocks, Grooved
2 3/4"x3/4"x3" BASSWOOD
Wing Mounting Blocks
2 3/16" dia.x2-1/2" BIRCH DOWELS
Pushrod Ends
2 5/16" dia.x1-
Wing Hold-Down Dowels
Spruce
5 1/8"x3/8"x36" Stringers, Stab and
Fin Brace
4 1/8"x3/4"x6" Main Spar Laminate 4 1/8"x3/4"x17-7/8" Main Spar
Laminate
4 1/8"x3/4"x30-1/8" Main Spar
Laminate
4 1/8"x3/4"x48" Main Spar Laminate 2 3/16"x1/2"x4-1/2" Spruce Spar
Doubler
6 1/4"x1/4"x36" Fuselage Main
Frame
1 1/4"x1/2"x 6" Tiller Bar
Mount
1 3/8"x3/8"x36" Servo Rails,
Elevator Joiner
Die-Cut Popular Plywood (Lite-Ply)
1 1/8"x8"x22" F-2, F-3, F-4, F-5, F-
6, F-l, F-B, F-9, F-10
1 1/8"x8"x22" F·1A, PT-1, PB-1,
Hatch Supports, Wing Center
Sheeting
1 1/8"x8"x22" PT-2 2 1/8"x8"x22" PS-1
2 1/8"x9"x22" WTR, W-1A,.W-4A,
SW-1, SW-2, SW-3
2 1/8"x6"x18" W·2, W-4 Wing Ribs 2 1/8"x9"x18" W-2, W-3, W-4
Wing Ribs
4 1/8"x12"x18" W-1, W-2, W-
3, W·4 Wing Ribs
1 1/8"x7"x36" PS-2, PB-2, G-1, TM,
TWM, F·6A, PF
1 1/8"x9-1/2"x36" SW-4 Shear
Webs
Die-Cut Birch Plywood
1 1/16"x10-1/2"x7" Instrument
Panel, JW·1, Dihedral Gauge,
Wheel Pant Plates
1 3/32"x4·1/2"x9" DB·3, DB-4,
Hold-Down Plates, L.G. Mount
Plates
2 5/32"x7·1/2"x8" F·1 1 5/32"x2-1/2"x17" DB·1, DB·2
1 5/32"x10"x12" JW-2, JW-3, IW-1,
IW-2
Sawn Plywood
12 1/8"x3/8"x10-1/2" LITE-PLY Rib
Stiffeners
2 1/64"x5/8"x48" BIRCH PLYWOOD
Wing Straps
2 3/32"x3"x4·1/4" BIRCH
PLYWOOD Servo Access Hatches
2 1/8"x1"x6" BIRCH PLYWOOD
PW
2 3/16"x1"x4" BIRCH PLYWOOD L.G.
Block Doublers
2 1/4"x4·11/32"x1-5/16" BIRCH
PLYWOOD JW-4
Wire Parts
1 3/32" dia. Straight Wire for Servo
End of Elevator Pushrod
1 1/8" dia. Formed Top Shock Strut
Wire
1 1/8" dia. Formed Bottom Shock
Strut Wire
1 3/16" dia. Formed Front Main
L.G. Wire
1 3/16" dia. Formed Rear Main L.G.
Wire
Plastic Parts
1 Left Dummy Engine Cylinders 1 Right Dummy Engine Cylinders 1 Cylinder Shrouds 1
Fuel Cap Cover, Shock Spring
Halves, Compass Halves
1 .030"x8-1/2"x17" Clear Butyrate
for Windshield
Fiberglass Parts
1 Cowling 2 Wheel Pants - LEFT AND RIGHT
ARE THE SAME
1 Left Wingtip 1 Right Wingtip
Miscellaneous Parts
1 1/2" dia. x3 ft Green Foam Cockpit
Coaming, Grooved
1 3/32" wide x7 ft Cockpit Lacing 1
32" long Fiberglass Pushrod Shaft
(for elevator)
1 12"x19" 6 oz. Fiberglass
Cloth (for L.G. & Wing Joint)
1 Small Nylon Tubing (for Rudder
Cable Guides & Throttle Pushrod)
1 20" long Steel Cable (for throttle
pushrod)
1 Full·Size Plans· Plate 1 1 Full·Size Plans - Plate 2
1 Full-Size Plans - Plate 3 1 Full-Size Plans - Plate 4 1 Decal Sheet 1 Instruction Book
Special Extruded Aluminum Parts
2 2" long Rear Wing Joiner Channels 2 3" long Front Wing Joiner
Channels
2 6" long Rear Wing Joiner Spars 2 9" long Front Wing Joiner
Spars
