SPALDING NBA Arena - Page 25

25
6.
Roll completed assembly to desired position.
After system is placed in an upright position,
COMPLETE the lling process in BOTH
bases.
If using WATER, the total amounts are as
follows:
Top Base: approx. 9.8 gallons (37.1 liters)
Bottom Base: approx. 49 gallons (186 liters)
If using SAND, the total amounts are as follows:
Top Base: approx. 117 lbs. (53.1 kg)
Bottom Base: approx. 590 lbs. (268 kg)
Rotate caps (33) securely into BOTH bases.
1
33
Make sure that the
anchor rope is centered.
NOTE:
266300
Cap (33) MUST be tightened
COMPLETELY and SECURELY to prevent
leakage.
CHECK WATER LEVEL BEFORE EACH
USE! FAILURE TO FOLLOW THIS
WARNING COULD RESULT IN SERIOUS
INJURY AND/OR PROPERTY DAMAGE.
WARNING!
266300
NON-TOXIC
ANTI-FREEZE
TWO CAPABLE ADULTS
REQUIRED FOR THIS
PROCEDURE. FAILURE TO
FOLLOW THIS WARNING
COULD RESULT IN SERIOUS
INJURY AND/OR PROPERTY
DAMAGE.
ADD AT LEAST ONE GALLON
(3.8 LITERS) OF NON-
TOXIC ANTIFREEZE IN TOP
BASE FOR SUB-FREEZING
CLIMATES.
IFUSINGSAND: 1 GALLON
OF ANTI-FREEZE IS NOT
REQUIRED.
CAUTION!
SAND
707 lb. (321
kg)
WARNING!
DO NOT LEAVE ASSEMBLY
UNATTENDED WHEN EMPTY;
IT MAY TIP OVER.
