SPALDING NBA Arena - Hardware Identification

5
IDENTIFY HARDWARE CARDS
BASE TO POLE
HARDWARE CARD
FRONT WHEEL ASSEMBLY
HARDWARE CARD
ELEVATOR TO POLE
CONNECTION HARDWARE CARD
ELEVATOR ARMS
HARDWARE BAG
BA00001
BA00002
EL00001
RIM ATTACHMENT
HARDWARE CARD AND BAG
STADIUM AND BOARD PAD
HARDWARE CARD
AC00001
To make the assembly easier we have separated the hardware per section.
Each hardware card is dedicated to a specic assembly area.
Open each individually as you progress through the steps. Do not open them all at once.
222700
208616
POLE TO POLE
HARDWARE BAG
207876 (3pcs)
205711 (4pcs)
206340 (7pcs)
203474 (14pcs)
201651 (4pcs)
AR00004
208251 (4pcs)
204620 (2pcs)
AR00004
